1814805 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN TNC JACK STR 50 OHM PCB
| Part | Dielectric Material | Contact Termination | Body Finish | Number of Ports | Operating Temperature [Max] | Operating Temperature [Min] | Connector Type | Mating Cycles | Mounting Type | Shield Termination | Frequency - Max [Max] | Housing Color | Body Material | Impedance | Center Contact Plating | Voltage Rating | Connector Style | Center Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Polytetrafluoroethylene (PTFE) | Solder | Nickel | 1 | 85 °C | -55 °C | Female Socket Jack | 500 | Through Hole | Solder | 4 GHz | Silver | Zinc | 50 Ohms | Gold | 500 V | TNC | Phosphor Bronze |
