846-012 Series
Manufacturer: EDAC Inc.
Beta
⌘K
846 HIGH TEMP' SERIES (.125" (3.
| Part | Material - Insulation | Termination Rows | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Pitch | Pitch | Mounting Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Termination | Card Type | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Read Out | Gender | Color | Contact Material | Number of Rows | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | Cantilever | 3.18 mm | 0.125 in | Right Angle Through Hole | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 12 | Solder | Non Specified - Single Edge | Gold | 125 °C | -40 C | 12 | Single | Female | Green | Copper Alloy | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | Cantilever | 3.18 mm | 0.125 in | Through Hole | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 12 | Solder | Non Specified - Single Edge | Gold | 125 °C | -40 C | 12 | Single | Female | Green | Copper Alloy | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 3.18 mm | 0.125 in | Through Hole | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 12 | Solder | Non Specified - Dual Edge | Gold | 125 °C | -40 C | 6 | Dual | Female | Green | Copper Alloy | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 3.18 mm | 0.125 in | Board Edge Straddle Mount | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 12 | Solder | Non Specified - Dual Edge | Gold | 125 °C | -40 C | 6 | Dual | Female | Green | Copper Alloy | 2 | 2 | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 3.18 mm | 0.125 in | Through Hole | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 12 | Solder | Non Specified - Dual Edge | Gold | 125 °C | -40 C | 6 | Dual | Female | Green | Copper Alloy | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | Cantilever | 3.18 mm | 0.125 in | Through Hole | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 12 | Solder | Non Specified - Single Edge | Gold | 125 °C | -40 C | 12 | Single | Female | Green | Copper Alloy | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 3.18 mm | 0.125 in | Through Hole | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 12 | Solder | Non Specified - Dual Edge | Gold | 125 °C | -40 C | 6 | Dual | Female | Green | Copper Alloy | 2 | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 3.18 mm | 0.125 in | Through Hole | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 12 | Wire Wrap | Non Specified - Dual Edge | Gold | 125 °C | -40 C | 6 | Dual | Female | Green | Copper Alloy | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | Cantilever | 3.18 mm | 0.125 in | Through Hole | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 12 | Solder Eyelet(s) | Non Specified - Single Edge | Gold | 125 °C | -40 C | 12 | Single | Female | Green | Copper Alloy | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 3.18 mm | 0.125 in | Board Edge Straddle Mount | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 12 | Solder Eyelet(s) | Non Specified - Dual Edge | Gold | 125 °C | -40 C | 6 | Dual | Female | Green | Copper Alloy | 2 | 2 | Card Extender |
