FMLB Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
POWER LINE FILTERS 1-STAGE MED 6A FMLB
| Part | Current | Voltage - Rated AC | Frequency - Operating [Max] | Frequency - Operating [Min] | Filter Type | Operating Temperature [Max] | Operating Temperature [Min] | Inductance | Applications | Approval Agency | Configuration | Termination Style | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | 6 A | 125 V 250 V | 60 Hz | 50 Hz | Single Phase | 100 °C | -25 °C | 1.8 mH | Medical | cURus ENEC VDE | Single Stage | Quick Connect | Chassis Mount |
 SCHURTER Inc. | 10 A | 125 V 250 V | 60 Hz | 50 Hz | Single Phase | 100 °C | -25 °C | 820 µH | Medical | cURus ENEC VDE | Single Stage | Quick Connect | Chassis Mount |
 SCHURTER Inc. | 6 A | 125 V 250 V | 60 Hz | 50 Hz | Single Phase | 100 °C | -25 °C | 1.8 mH | General Purpose | cURus ENEC VDE | Single Stage | Quick Connect | Chassis Mount |
 SCHURTER Inc. | 4 A | 125 V 250 V | 60 Hz | 50 Hz | Single Phase | 100 °C | -25 °C | 1.5 mH | Medical | cURus ENEC VDE | Single Stage | Quick Connect | Chassis Mount |
 SCHURTER Inc. | 16 A | 125 V 250 V | 60 Hz | 50 Hz | Single Phase | 100 °C | -25 °C | 2 mH | Medical | cURus ENEC VDE | Single Stage | Quick Connect | Chassis Mount |
