ACB24 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN EDGE DUAL FMALE 48POS 0.050

Part	Material - Insulation	Number of Rows [custom]	Read Out	Number of Positions/Bay/Row	Pitch	Pitch	Contact Material	Features	Card Thickness	Card Thickness	Number of Positions	Card Type	Color	Gender	Contact Type	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish Thickness	Contact Finish Thickness	Mounting Type	Contact Finish	Termination	Flange Feature [diameter]	Flange Feature	Flange Feature [diameter]	Flange Feature [custom]	Flange Feature [custom]
Sullins Connector Solutions ACB24DHHR	Polyphenylene Sulfide (PPS)	2	Dual	24	0.05 in	1.27 mm	Beryllium Copper	Board Lock	1.57 mm	0.062 in	48	Non Specified - Dual Edge	Black	Female	Hairpin Bellows	150 °C	-65 ░C	30 Áin	0.76 Ám	Through Hole	Gold	Solder Staggered
Sullins Connector Solutions ACB24DHFR	Polyphenylene Sulfide (PPS)	2	Dual	24	0.05 in	1.27 mm	Beryllium Copper	Board Lock	1.57 mm	0.062 in	48	Non Specified - Dual Edge	Black	Female	Hairpin Bellows	150 °C	-65 ░C	30 Áin	0.76 Ám	Surface Mount	Gold	Solder
Sullins Connector Solutions ACB24DYFR	Polyphenylene Sulfide (PPS)	2	Dual	24	0.05 in	1.27 mm	Beryllium Copper	Board Lock	1.57 mm	0.062 in	48	Non Specified - Dual Edge	Black	Female	Cantilever	150 °C	-65 ░C	30 Áin	0.76 Ám	Surface Mount	Gold	Solder
Sullins Connector Solutions ACB24DYRN-S1355	Polyphenylene Sulfide (PPS)	2	Dual	24	0.05 in	1.27 mm	Beryllium Copper	Card Extender	1.57 mm	0.062 in	48	Non Specified - Dual Edge	Black	Female	Cantilever	150 °C	-65 ░C	30 Áin	0.76 Ám	Board Edge Straddle Mount	Gold	Solder
Sullins Connector Solutions ACB24DKBS	Polyphenylene Sulfide (PPS)	2	Dual	24	0.1 "	2.54 mm	Beryllium Copper	Bi-Level - High Density	1.57 mm	0.062 in	48	Non Specified - Dual Edge Bi-Level	Black	Female	Cantilever	150 °C	-65 ░C	30 Áin	0.76 Ám	Right Angle Through Hole	Gold	Solder	0.125 "	Side Mount Opening Unthreaded	3.18 mm
Sullins Connector Solutions ACB24DHHT	Polyphenylene Sulfide (PPS)	2	Dual	24	0.05 in	1.27 mm	Beryllium Copper		1.57 mm	0.062 in	48	Non Specified - Dual Edge	Black	Female	Hairpin Bellows	150 °C	-65 ░C	30 Áin	0.76 Ám	Through Hole	Gold	Solder Staggered		4-40 Flush Mount Threaded Insert Top Opening
Sullins Connector Solutions ACB24DYRQ	Polyphenylene Sulfide (PPS)	2	Dual	24	0.05 in	1.27 mm	Beryllium Copper	Card Extender	1.57 mm	0.062 in	48	Non Specified - Dual Edge	Black	Female	Cantilever	150 °C	-65 ░C	30 Áin	0.76 Ám	Board Edge Straddle Mount	Gold	Solder		Straddle Mount Opening Unthreaded		1.98 mm	0.078 "
Sullins Connector Solutions ACB24DYHN-S1355	Polyphenylene Sulfide (PPS)	2	Dual	24	0.05 in	1.27 mm	Beryllium Copper		1.57 mm	0.062 in	48	Non Specified - Dual Edge	Black	Female	Cantilever	150 °C	-65 ░C	30 Áin	0.76 Ám	Through Hole	Gold	Solder Staggered
Sullins Connector Solutions ACB24DYHD	Polyphenylene Sulfide (PPS)	2	Dual	24	0.05 in	1.27 mm	Beryllium Copper		1.57 mm	0.062 in	48	Non Specified - Dual Edge	Black	Female	Cantilever	150 °C	-65 ░C	30 Áin	0.76 Ám	Through Hole	Gold	Solder Staggered	0.125 "	Flush Mount Top Opening Unthreaded	3.18 mm
Sullins Connector Solutions ACB24DHHN	Polyphenylene Sulfide (PPS)	2	Dual	24	0.05 in	1.27 mm	Beryllium Copper		1.57 mm	0.062 in	48	Non Specified - Dual Edge	Black	Female	Hairpin Bellows	150 °C	-65 ░C	30 Áin	0.76 Ám	Through Hole	Gold	Solder Staggered
