887-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 44POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Gender | Contact Type | Pitch | Pitch | Card Type | Features | Termination | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Color | Number of Positions | Number of Positions/Bay/Row | Mounting Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Cantilever | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Card Extender | Solder | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Black | 44 | 22 | Board Edge Straddle Mount | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Cantilever | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Black | 44 | 22 | Right Angle Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Cantilever | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder Eyelet(s) | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Black | 44 | 22 | Through Hole | 3.96 mm | 0.156 " | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Cantilever | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Black | 44 | 22 | Through Hole | 2 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Cantilever | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Wire Wrap | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Black | 44 | 22 | Through Hole | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 2 | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Cantilever | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Black | 44 | 22 | Through Hole | 3.96 mm | 0.156 " | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Cantilever | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Card Extender | Solder | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Black | 44 | 22 | Board Edge Straddle Mount | 3.96 mm | 0.156 " | 2 | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Cantilever | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Black | 44 | 22 | Through Hole | 3.96 mm | 0.156 " | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Cantilever | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Black | 44 | 22 | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Cantilever | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Black | 44 | 22 | Right Angle Through Hole | 3.96 mm | 0.156 " | 2 |
