ET110F Series
Manufacturer: Nidec Components Corporation
Beta
⌘K
SWITCH TOGGLE SPDT 10A 125V
| Part | Electrical Life | Switch Function | Actuator Length [x] | Panel Cutout Dimensions [diameter] | Actuator Type | Voltage Rating - AC | Illumination | Termination Style | Bushing Thread | Circuit | Current Rating (Amps) | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Nidec Components Corporation | 20000 Steps | On-Mom | 17 mm | 12.5 mm | Standard Round | 125 V | Non-Illuminated | Quick Connect - 0.250" (6.3mm) | M12 x 1 | SPDT | 10 A | Panel Mount |
 Nidec Components Corporation | 20000 Steps | On-Mom | 17 mm | 12.5 mm | Standard Round | 125 V | Non-Illuminated | Solder Lug | M12 x 1 | SPDT | 10 A | Panel Mount |
