887-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 29POS 0.156
| Part | Termination Rows | Material - Insulation | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Read Out | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Gender | Contact Material | Number of Positions/Bay/Row | Color | Flange Feature | Termination | Number of Positions | Card Type | Pitch | Pitch | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Right Angle Through Hole | Female | Copper Alloy | 29 | Black | M3 Threaded Insert Top Mount Opening | Solder | 29 | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Right Angle Through Hole | Female | Copper Alloy | 29 | Black | Floating Bobbin Top Mount Opening | Solder | 29 | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Through Hole | Female | Copper Alloy | 29 | Black | Floating Bobbin Flush Mount | Wire Wrap | 29 | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Right Angle Through Hole | Female | Copper Alloy | 29 | Black | M3 Threaded Insert Top Mount Opening | Solder | 29 | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Through Hole | Female | Copper Alloy | 29 | Black | Flush Mount M3 Threaded Insert Top Opening | Solder Eyelet(s) | 29 | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Through Hole | Female | Copper Alloy | 29 | Black | 4-40 Flush Mount Threaded Insert Top Opening | Wire Wrap | 29 | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Through Hole | Female | Copper Alloy | 29 | Black | Wire Wrap | 29 | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Through Hole | Female | Copper Alloy | 29 | Black | Flush Mount Top Opening Unthreaded | Solder | 29 | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Through Hole | Female | Copper Alloy | 29 | Black | Flush Mount Top Opening Unthreaded | Solder Eyelet(s) | 29 | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Through Hole | Female | Copper Alloy | 29 | Black | Solder Eyelet(s) | 29 | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | 0.128 " | 3.25 mm |
