333-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 14POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Read Out | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Card Type | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Gender | Pitch | Pitch | Color | Number of Positions/Bay/Row | Termination | Contact Finish | Contact Type | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 2 | Non Specified - Dual Edge | 14 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Female | 3.96 mm | 0.156 in | Green | 7 | Wire Wrap | Gold | Cantilever | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 14 | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Female | 3.96 mm | 0.156 in | Green | 14 | Solder | Gold | Cantilever | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 2 | Non Specified - Dual Edge | 14 | Flush Mount M3 Threaded Insert Top Opening | Female | 3.96 mm | 0.156 in | Green | 7 | Solder Eyelet(s) | Gold | Cantilever | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 2 | Non Specified - Dual Edge | 14 | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Female | 3.96 mm | 0.156 in | Green | 7 | Solder | Gold | Cantilever | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 14 | 3.96 mm | 0.156 " | Female | 3.96 mm | 0.156 in | Green | 14 | Solder | Gold | Cantilever | 1 | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 2 | Non Specified - Dual Edge | 14 | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Female | 3.96 mm | 0.156 in | Green | 7 | Solder | Gold | Cantilever | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 14 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Female | 3.96 mm | 0.156 in | Green | 14 | Wire Wrap | Gold | Cantilever | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Board Edge Straddle Mount | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 2 | Non Specified - Dual Edge | 14 | M3 Threaded Insert Top Mount Opening | Female | 3.96 mm | 0.156 in | Green | 7 | Solder | Gold | Cantilever | Card Extender | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 14 | Female | 3.96 mm | 0.156 in | Green | 14 | Wire Wrap | Gold | Cantilever | 1 | 1 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Board Edge Straddle Mount | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 2 | Non Specified - Dual Edge | 14 | Female | 3.96 mm | 0.156 in | Green | 7 | Solder | Gold | Cantilever | Card Extender |
