307-010 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 10POS 0.156
| Part | Termination Rows | Material - Insulation | Pitch | Pitch | Card Type | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Type | Number of Rows | Number of Positions/Bay/Row | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Color | Termination | Mounting Type | Read Out | Contact Finish | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Gender | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Semi Bellows | 1 | 10 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Solder | Right Angle Through Hole | Single | Gold | 10 | 0.25 Ám | 10 Áin | Female | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Semi Bellows | 1 | 10 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Solder | Right Angle Through Hole | Single | Tin | 10 | Female | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 10 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Solder Eyelet(s) | Through Hole | Dual | Tin | 20 | Female | 2 | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Semi Bellows | 10 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Solder | Right Angle Through Hole | Dual | Tin | 20 | Female | 2 | |||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 1 | 10 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Solder | Through Hole | Single | Gold | 10 | 0.25 Ám | 10 Áin | Female | Card Guides | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 1 | 10 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Solder | Right Angle Through Hole | Single | Tin | 10 | Female | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Semi Bellows | 10 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Solder | Right Angle Through Hole | Dual | Tin | 20 | Female | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 1 | 10 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Solder | Right Angle Through Hole | Single | Gold | 10 | 0.25 Ám | 10 Áin | Female | Card Guides | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 10 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Wire Wrap | Right Angle Through Hole | Dual | Gold | 20 | 0.25 Ám | 10 Áin | Female | 2 | Card Guides | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 1 | 10 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Green | Solder | Through Hole | Single | Tin | 10 | Female | Card Guides |
