284513 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
22 POS TERMI-BLOK HDR 900 POL.
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Header Orientation | Mounting Type | Insulation Height | Insulation Height | Contact Mating Finish | Contact Material | Color | Number of Positions | Pitch [x] | Pitch [x] | Material Flammability Rating | Contact Tail Length | Contact Tail Length | Type | Voltage - UL | Current - UL | Positions Per Level | Termination Style | Number of Levels | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 90° Right Angle | Through Hole | 7.3 mm | 0.287 in | Tin | Phosphor Bronze | Green | 22 positions | 0.15 in | 3.81 mm | UL94 V-0 | 3.4 mm | 0.134 in | Header Male Pins Shrouded (4 Side) | 300 V | 11 A | 22 | Solder | 1 | |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 90° Right Angle | Through Hole | 7.3 mm | 0.287 in | Tin | Phosphor Bronze | Green | 2 | 0.15 in | 3.81 mm | UL94 V-0 | 3.4 mm | 0.134 in | Header Male Pins Shrouded (4 Side) | 300 V | 11 A | 2 | Solder | 1 | |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 90° Right Angle | Through Hole | 7.3 mm | 0.287 in | Tin | Phosphor Bronze | Green | 0.15 in | 3.81 mm | UL94 V-0 | 3.4 mm | 0.134 in | Header Male Pins Shrouded (4 Side) | 300 V | 11 A | 3 | Solder | 1 | ||
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 90° Right Angle | Through Hole | 7.3 mm | 0.287 in | Tin | Phosphor Bronze | Green | 4 | 0.15 in | 3.81 mm | UL94 V-0 | 3.4 mm | 0.134 in | Header Male Pins Shrouded (4 Side) | 300 V | 11 A | 4 | Solder | 1 | |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 90° Right Angle | Through Hole | 7.3 mm | 0.287 in | Tin | Phosphor Bronze | Green | 0.15 in | 3.81 mm | UL94 V-0 | 3.4 mm | 0.134 in | Header Male Pins Shrouded (4 Side) | 300 V | 11 A | 5 | Solder | 1 | ||
TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 90° Right Angle | Through Hole | 7.3 mm | 0.287 in | Tin | Phosphor Bronze | Green | 15 | 0.15 in | 3.81 mm | UL94 V-0 | 3.4 mm | 0.134 in | Header Male Pins Shrouded (4 Side) | 300 V | 11 A | 15 | Solder | 1 | |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 90° Right Angle | Through Hole | 7.3 mm | 0.287 in | Tin | Phosphor Bronze | Green | 0.15 in | 3.81 mm | UL94 V-0 | 3.4 mm | 0.134 in | Header Male Pins Shrouded (4 Side) | 300 V | 11 A | 16 | Solder | 1 | 16 | |
TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 90° Right Angle | Through Hole | 7.3 mm | 0.287 in | Tin | Phosphor Bronze | Green | 23 | 0.15 in | 3.81 mm | UL94 V-0 | 3.4 mm | 0.134 in | Header Male Pins Shrouded (4 Side) | 300 V | 11 A | 23 | Solder | 1 | |
TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 90° Right Angle | Through Hole | 7.3 mm | 0.287 in | Tin | Phosphor Bronze | Green | 9 | 0.15 in | 3.81 mm | UL94 V-0 | 3.4 mm | 0.134 in | Header Male Pins Shrouded (4 Side) | 300 V | 11 A | 9 | Solder | 1 | |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | 90° Right Angle | Through Hole | 7.3 mm | 0.287 in | Tin | Phosphor Bronze | Green | 24 | 0.15 in | 3.81 mm | UL94 V-0 | 3.4 mm | 0.134 in | Header Male Pins Shrouded (4 Side) | 300 V | 11 A | Solder | 1 |
