E2E-X4 Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
SENSOR INDUCT 4MM PNP M8 NO
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Sensing Distance | Sensing Distance | Package / Case | Ingress Protection | Material - Body | Shielding | Termination Style | Voltage - Supply [Max] | Voltage - Supply [Min] | Response Frequency | Indicator [custom] | Sensor Type | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Omron Electronics Inc-EMC Div | 85 °C | -40 °C | 4 mm | 0.157 in | Cylinder Threaded - M8 | IP67 IP69K | Stainless Steel | Unshielded | Cable Leads | 30 VDC | 10 VDC | 1 kHz | LED | Inductive | PNP-NO 3-Wire |
Omron Electronics Inc-EMC Div | 60 °C | -25 °C | 4 mm | 0.157 in | Cylinder Threaded - M8 | IP67 IP69K | Nickel-Plated Brass | Shielded | Cable with Connector | 30 VDC | 10 VDC | 700 Hz | LED | Inductive | PNP-NC 3-Wire |
Omron Electronics Inc-EMC Div | 85 °C | -40 °C | 4 mm | 0.157 in | Cylinder Threaded - M8 | IP67 IP69K | Stainless Steel | Unshielded | Cable Leads | 30 VDC | 10 VDC | 1 kHz | LED | Inductive | PNP-NC 3-Wire |
 Omron Electronics Inc-EMC Div | 85 °C | -40 °C | 4 mm | 0.157 in | Cylinder Threaded - M12 | IP67 IP69K | Nickel-Plated Brass | Shielded | Cable Leads | 30 VDC | 10 VDC | 1 kHz | LED | Inductive | PNP-NO 3-Wire |
Omron Electronics Inc-EMC Div | 70 °C | -25 °C | 4 mm | 0.157 in | Cylinder Threaded - M8 | IP67 | Stainless Steel | Unshielded | Cable Leads | 30 VDC | 10 VDC | 1 kHz | LED | Inductive | 2-Wire NPN-NO |
Omron Electronics Inc-EMC Div | 85 °C | -40 °C | 4 mm | 0.157 in | Cylinder Threaded - M8 | IP67 IP69K | Stainless Steel | Unshielded | Cable Leads | 30 VDC | 10 VDC | 1 kHz | LED | Inductive | PNP-NC 3-Wire |
Omron Electronics Inc-EMC Div | 60 °C | -25 °C | 4 mm | 0.157 in | Cylinder Threaded - M8 | IP67 IP69K | Nickel-Plated Brass | Shielded | Cable with Connector | 30 VDC | 10 VDC | 700 Hz | LED | Inductive | PNP-NO 3-Wire |
Omron Electronics Inc-EMC Div | 70 °C | -25 °C | 4 mm | 0.157 in | Cylinder Threaded - M12 | IP67 IP69K | Nickel-Plated Brass | Shielded | Cable Leads | 30 VDC | 10 VDC | 1 kHz | LED | Inductive | PNP-NO 3-Wire |
Omron Electronics Inc-EMC Div | 70 °C | -25 °C | 4 mm | 0.157 in | Cylinder Threaded - M12 | IP67 IP69K | Nickel-Plated Brass | Shielded | Connector | 30 VDC | 10 VDC | 1 kHz | LED | Inductive | PNP-NC/NO 3-Wire |
Omron Electronics Inc-EMC Div | 70 °C | -25 °C | 4 mm | 0.157 in | Cylinder Threaded - M12 | IP67 IP69K | Nickel-Plated Brass | Shielded | Cable Leads | 30 VDC | 10 VDC | 1 kHz | LED | Inductive | PNP-NO 3-Wire |
