RT9058 Series

Catalog

IC REG LINEAR 3.3V 100MA SOT23-3

Part	Current - Output	Protection Features	Output Configuration	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Current - Supply (Max) [Max]	Number of Regulators	Package / Case	PSRR [Max]	PSRR [Min]	Voltage - Output (Min/Fixed)	Voltage Dropout (Max)	Current - Quiescent (Iq)	Voltage - Input (Max) [Max]
Richtek USA Inc. RT9058-33GV	100 mA	Over Current	Positive	SOT-23-3	85 C	-40 ¯C	Surface Mount	5 µA	1	SC-59 SOT-23-3 TO-236-3	70 dB	40 dB	3.3 V	0.5 V	3.5 µA	36 V
Richtek USA Inc. RT9058-C0GX	100 mA	Over Current	Positive	SOT-89-3	85 C	-40 ¯C	Surface Mount	5 µA	1	TO-243AA	70 dB	40 dB	12 V	0.5 V	5 µA	36 V
Richtek USA Inc. RT9058-25GV	100 mA	Over Current	Positive	SOT-23-3	85 C	-40 ¯C	Surface Mount	5 µA	1	SC-59 SOT-23-3 TO-236-3	70 dB	40 dB	2.5 V	0.5 V	3.5 µA	36 V
Richtek USA Inc. RT9058-33GX	100 mA	Over Current	Positive	SOT-89-3	85 C	-40 ¯C	Surface Mount	5 µA	1	TO-243AA	70 dB	40 dB	3.3 V	0.5 V	3.5 µA	36 V
Richtek USA Inc. RT9058-30GVL	100 mA	Over Current	Positive	SOT-23-3L	85 C	-40 ¯C	Surface Mount		1	SC-59 SOT-23-3 TO-236-3	70 dB	40 dB	3 V	0.5 V	3.5 µA	36 V
Richtek USA Inc. RT9058-50GV	100 mA	Over Current	Positive	SOT-23-3	85 C	-40 ¯C	Surface Mount	5 µA	1	SC-59 SOT-23-3 TO-236-3	70 dB	40 dB	5 V	0.5 V	3.5 µA	36 V
Richtek USA Inc. RT9058-90GVL	100 mA	Over Current	Positive	SOT-23-3L	85 C	-40 ¯C	Surface Mount		1	SC-59 SOT-23-3 TO-236-3	70 dB	40 dB	9 V	0.5 V	5 µA	36 V
Richtek USA Inc. RT9058-50GVL	100 mA	Over Current	Positive	SOT-23-3L	85 C	-40 ¯C	Surface Mount	5 µA	1	SC-59 SOT-23-3 TO-236-3	70 dB	40 dB	5 V	0.5 V	3.5 µA	36 V
Richtek USA Inc. RT9058-60GVL	100 mA	Over Current	Positive	SOT-23-3L	85 C	-40 ¯C	Surface Mount		1	SC-59 SOT-23-3 TO-236-3	70 dB	40 dB	6 V	0.5 V	5 µA	36 V
Richtek USA Inc. RT9058-C0GV	100 mA	Over Current	Positive	SOT-23-3	85 C	-40 ¯C	Surface Mount	5 µA	1	SC-59 SOT-23-3 TO-236-3	70 dB	40 dB	12 V	0.5 V	5 µA	36 V
