39S Series

Catalog

POWER INDUCTOR (SMD), 2.5 ΜH, 10 A, UNSHIELDED, 10 A, 3900 SERIES

Part	Operating Temperature [Max]	Operating Temperature [Min]	Shielding	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Package / Case	Inductance Frequency - Test	Current Rating (Amps)	Current - Saturation (Isat)	Inductance	DC Resistance (DCR) [Max]	Type	Tolerance	Mounting Type	DC Resistance (DCR)
Murata Electronics 39S252C	125 °C	-40 C	Unshielded	0.228 "	5.8 mm	12.9 mm	0.508 in	12.9 mm	0.508 in	Nonstandard	100 kHz	10 A	10 A	2.5 µH	3.9 mOhm	Wirewound	20 %	Surface Mount
Murata Electronics 39S602C	125 °C	-40 C	Unshielded	0.228 "	5.8 mm	12.9 mm	0.508 in	12.9 mm	0.508 in	Nonstandard	100 kHz	6.7 A	6.7 A	6 ÁH	8 mOhm	Wirewound	20 %	Surface Mount
Murata Electronics 39S103C	125 °C	-40 C	Unshielded	0.228 "	5.8 mm	12.9 mm	0.508 in	12.9 mm	0.508 in	Nonstandard	100 kHz	5 A	5 A	10 µH		Wirewound	20 %	Surface Mount	13.5 mOhm
Murata Electronics 39S152C	125 °C	-40 C	Unshielded	0.228 "	5.8 mm	12.9 mm	0.508 in	12.9 mm	0.508 in	Nonstandard	100 kHz	13.5 A	14 A	1.5 µH	2.5 mOhm	Wirewound	30 %	Surface Mount
Murata Electronics 39S681C	125 °C	-40 C	Unshielded	0.228 "	5.8 mm	12.9 mm	0.508 in	12.9 mm	0.508 in	Nonstandard	100 kHz	19.5 A	20.4 A	0.68 µH	1.9 mOhm	Wirewound	30 %	Surface Mount
