055447 Series

Manufacturer: Molex

Catalog

CONN HEADER VERT 20POS 1.25MM

Part	Overall Contact Length	Overall Contact Length	Termination	Mated Stacking Heights	Contact Shape	Connector Type	Number of Positions Loaded	Mounting Type	Contact Material	Insulation Material	Pitch - Mating	Pitch - Mating	Number of Positions	Insulation Color	Insulation Height	Insulation Height	Number of Rows	Contact Finish - Post	Shrouding	Features	Fastening Type	Contact Length - Post	Contact Length - Post	Material Flammability Rating	Style	Contact Length - Mating	Contact Length - Mating	Contact Type
Molex 0554472080	8.2 mm	0.323 in	Press-Fit Solder	8.4 mm	Square	Header	All	Through Hole	Brass	Nylon Polyamide (PA)	1.25 mm	0.049 in	20	Natural	0.303 in	7.7 mm	1	Tin	Shrouded - 4 Wall	Board Guide	Latch Lock	0.118 in	3 mm	UL94 V-0	Board to Cable/Wire	0.11 in	2.79 mm	Male Pin
Molex 0554470670	8.2 mm	0.323 in	Press-Fit Solder	8.4 mm	Square	Header	All	Through Hole	Brass	Nylon Polyamide (PA)	1.25 mm	0.049 in	6	Natural	0.303 in	7.7 mm	1	Tin	Shrouded - 4 Wall	Board Guide	Latch Lock	0.118 in	3 mm	UL94 V-0	Board to Cable/Wire	0.11 in	2.79 mm	Male Pin
Molex 0554472070	8.2 mm	0.323 in	Press-Fit Solder	8.4 mm	Square	Header	All	Through Hole	Brass	Nylon Polyamide (PA)	1.25 mm	0.049 in	20	Natural	0.303 in	7.7 mm	1	Tin	Shrouded - 4 Wall	Board Guide	Latch Lock	0.118 in	3 mm	UL94 V-0	Board to Cable/Wire	0.11 in	2.79 mm	Male Pin
Molex 0554470570	8.2 mm	0.323 in	Press-Fit Solder	8.4 mm	Square	Header	All	Through Hole	Brass	Nylon Polyamide (PA)	1.25 mm	0.049 in		Natural	0.303 in	7.7 mm	1	Tin	Shrouded - 4 Wall	Board Guide	Latch Lock	0.118 in	3 mm	UL94 V-0	Board to Cable/Wire	0.11 in	2.79 mm	Male Pin
Molex 0554470870	8.2 mm	0.323 in	Press-Fit Solder	8.4 mm	Square	Header	All	Through Hole	Brass	Nylon Polyamide (PA)	1.25 mm	0.049 in	8	Natural	0.303 in	7.7 mm	1	Tin	Shrouded - 4 Wall	Board Guide	Latch Lock	0.118 in	3 mm	UL94 V-0	Board to Cable/Wire	0.11 in	2.79 mm	Male Pin
Molex 0554471470	8.2 mm	0.323 in	Press-Fit Solder	8.4 mm	Square	Header	All	Through Hole	Brass	Nylon Polyamide (PA)	1.25 mm	0.049 in	14	Natural	0.303 in	7.7 mm	1	Tin	Shrouded - 4 Wall	Board Guide	Latch Lock	0.118 in	3 mm	UL94 V-0	Board to Cable/Wire	0.11 in	2.79 mm	Male Pin
Molex 0554470370	8.2 mm	0.323 in	Press-Fit Solder	8.4 mm	Square	Header	All	Through Hole	Brass	Nylon Polyamide (PA)	1.25 mm	0.049 in		Natural	0.303 in	7.7 mm	1	Tin	Shrouded - 4 Wall	Board Guide	Latch Lock	0.118 in	3 mm	UL94 V-0	Board to Cable/Wire	0.11 in	2.79 mm	Male Pin
