11_QN-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
11_QN-50-3-3/113_NE
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating | Center Contact Plating | Body Material | Body Finish | Dielectric Material | Connector Style | Mounting Type | Shield Termination | Center Contact Material | Connector Type | Housing Color | Contact Termination | Cable Group | Fastening Type | Number of Ports | Impedance | Frequency - Max [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | 125 °C | -40 C | 1000 VDC | Gold | Brass | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | QN | Free Hanging (In-Line) | Solder | Beryllium Copper | Plug Male Pin | Gold | Crimp | RG-141 | Push-Pull | 1 | 50 Ohms | 11 GHz |
 Huber+Suhner, Inc. | 125 °C | -40 C | 1000 VDC | Gold | Brass | White Bronze | Polytetrafluoroethylene (PTFE) | QN | Free Hanging (In-Line) | Crimp | Bronze | Plug Male Pin | Silver | Crimp | LMR-500 | Push-Pull | 1 | 50 Ohms | 11 GHz |
 Huber+Suhner, Inc. | 125 °C | -40 C | 1000 VDC | Gold | Brass | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | QN | Free Hanging (In-Line) | Crimp | Brass | Plug Male Pin | Silver | Crimp | RG-213 | Push-Pull | 1 | 50 Ohms | 11 GHz |
 Huber+Suhner, Inc. | 125 °C | -40 C | 1000 VDC | Gold | Brass | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | QN | Free Hanging (In-Line) | Crimp | Brass | Plug Male Pin | Silver | Crimp | RG-58 | Push-Pull | 1 | 50 Ohms | 11 GHz |
 Huber+Suhner, Inc. | 125 °C | -40 C | 1000 VDC | Gold | Brass | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | QN | Free Hanging (In-Line) | Crimp | Brass | Plug Male Pin | Silver | Crimp | RG-214 | Push-Pull | 1 | 50 Ohms | 11 GHz |
Huber+Suhner, Inc. | 125 °C | -40 C | 1000 VDC | Gold | Brass | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | QN | Free Hanging (In-Line) | Crimp | Brass | Plug Male Pin | Silver | Crimp | RG-393 | Push-Pull | 1 | 50 Ohms | 11 GHz |
 Huber+Suhner, Inc. | 125 °C | -40 C | 1000 VDC | Gold | Brass | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | QN | Free Hanging (In-Line) | Crimp | Brass | Plug Male Pin | Silver | Crimp | RG-400 | Push-Pull | 1 | 50 Ohms | 11 GHz |
Huber+Suhner, Inc. | 125 °C | -40 C | 1000 VDC | Gold | Brass | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | QN | Free Hanging (In-Line) | Crimp | Brass | Plug Male Pin | Silver | Crimp | LMR-240 | Push-Pull | 1 | 50 Ohms | 11 GHz |
