SL1000 Series

Catalog

POWER SUPPLY PROGRAMED DC 2.6 KW

Part	Current Regulation - Load	Current Regulation - Line	Weight	Weight	Voltage Regulation - Load	Voltage Regulation - Line	Accuracy - Voltmeter; Ammeter	Ripple	Features	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Display Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Power (Watts)	Type	Current - Output [Max]	Number of Characters	Voltage - Output [Max]	Voltage - Supply
Magna-Power Electronics SL1000-2.6/UI2+LXI	0.04 %	0.02 %	15.4 kg	34 lbs	0.01 %	0.004 %	0.2 %	350 mV	Ethernet Programmable RS-232 Tracking	1.72 " 44.5 mm	24 in 609.6 mm	19 in 482.6 mm	LED	187 VAC	265 VAC	2600 W	Rack Mount (AC to DC)	2.6 A	3.5 4	1 kVDC
Magna-Power Electronics SL1000-1.5/UI+LXI	0.04 %	0.02 %	14.5 kg	32 lbs	0.01 %	0.004 %	0.2 %	350 mV	Ethernet Programmable RS-232 Tracking	1.72 " 44.5 mm	24 in 609.6 mm	19 in 482.6 mm	LED	85 VAC/DC	265 VAC	1500 W	Rack Mount (AC to DC)	1.5 A	3.5 4	1 kVDC
Magna-Power Electronics SL1000-8/208+LXI	0.04 %	0.02 %	16.3 kg	36 lbs	0.01 %	0.004 %	0.2 %	350 mV	Ethernet Programmable RS-232 Tracking	1.72 " 44.5 mm	24 in 609.6 mm	19 in 482.6 mm	LED			8000 W	Rack Mount (AC to DC)	8 A	3.5 4	1 kVDC	208 VAC
Magna-Power Electronics SL1000-8/480+LXI	0.04 %	0.02 %	16.3 kg	36 lbs	0.01 %	0.004 %	0.2 %	350 mV	Ethernet Programmable RS-232 Tracking	1.72 " 44.5 mm	24 in 609.6 mm	19 in 482.6 mm	LED			8000 W	Rack Mount (AC to DC)	8 A	3.5 4	1 kVDC	480 VAC
Magna-Power Electronics SL1000-1.5/208+LXI	0.04 %	0.02 %	14.5 kg	32 lbs	0.01 %	0.004 %	0.2 %	350 mV	Ethernet Programmable RS-232 Tracking	1.72 " 44.5 mm	24 in 609.6 mm	19 in 482.6 mm	LED			1500 W	Rack Mount (AC to DC)	1.5 A	3.5 4	1 kVDC	208 VAC
Magna-Power Electronics SL1000-2.6/208+LXI	0.04 %	0.02 %	15.4 kg	34 lbs	0.01 %	0.004 %	0.2 %	350 mV	Ethernet Programmable RS-232 Tracking	1.72 " 44.5 mm	24 in 609.6 mm	19 in 482.6 mm	LED			2600 W	Rack Mount (AC to DC)	2.6 A	3.5 4	1 kVDC	208 VAC
Magna-Power Electronics SL1000-6/480+LXI	0.04 %	0.02 %	15.9 kg	35 lbs	0.01 %	0.004 %	0.2 %	350 mV	Ethernet Programmable RS-232 Tracking	1.72 " 44.5 mm	24 in 609.6 mm	19 in 482.6 mm	LED			6000 W	Rack Mount (AC to DC)	6 A	3.5 4	1 kVDC	480 VAC
Magna-Power Electronics SL1000-4/208+LXI	0.04 %	0.02 %	15.9 kg	35 lbs	0.01 %	0.004 %	0.2 %	350 mV	Ethernet Programmable RS-232 Tracking	1.72 " 44.5 mm	24 in 609.6 mm	19 in 482.6 mm	LED			4000 W	Rack Mount (AC to DC)	4 A	3.5 4	1 kVDC	208 VAC
Magna-Power Electronics SL1000-2.6/480+LXI	0.04 %	0.02 %	15.4 kg	34 lbs	0.01 %	0.004 %	0.2 %	350 mV	Ethernet Programmable RS-232 Tracking	1.72 " 44.5 mm	24 in 609.6 mm	19 in 482.6 mm	LED			2600 W	Rack Mount (AC to DC)	2.6 A	3.5 4	1 kVDC	480 VAC
Magna-Power Electronics SL1000-6/208+LXI	0.04 %	0.02 %	15.9 kg	35 lbs	0.01 %	0.004 %	0.2 %	350 mV	Ethernet Programmable RS-232 Tracking	1.72 " 44.5 mm	24 in 609.6 mm	19 in 482.6 mm	LED			6000 W	Rack Mount (AC to DC)	6 A	3.5 4	1 kVDC	208 VAC
