896-021 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 21POS 0.125
| Part | Material - Insulation | Termination Rows | Gender | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Color | Number of Positions | Read Out | Number of Positions/Bay/Row [custom] | Contact Type | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Card Type | Contact Material | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 21 | Single | 21 | Cantilever | 1 | 0.25 Ám | 10 Áin | Through Hole | Non Specified - Single Edge | Copper Alloy | 3.18 mm | 0.125 in | 125 °C | -40 C | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Wire Wrap |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 21 | Single | 21 | Cantilever | 1 | 0.25 Ám | 10 Áin | Through Hole | Non Specified - Single Edge | Copper Alloy | 3.18 mm | 0.125 in | 125 °C | -40 C | 4-40 Threaded Insert Top Mount Opening | Solder | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 21 | Single | 21 | Cantilever | 1 | 0.25 Ám | 10 Áin | Right Angle Through Hole | Non Specified - Single Edge | Copper Alloy | 3.18 mm | 0.125 in | 125 °C | -40 C | 4-40 Threaded Insert Top Mount Opening | Solder | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 21 | Single | 21 | Cantilever | 1 | 0.25 Ám | 10 Áin | Right Angle Through Hole | Non Specified - Single Edge | Copper Alloy | 3.18 mm | 0.125 in | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | Solder | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 21 | Single | 21 | Cantilever | 1 | 0.25 Ám | 10 Áin | Through Hole | Non Specified - Single Edge | Copper Alloy | 3.18 mm | 0.125 in | 125 °C | -40 C | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Wire Wrap |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 21 | Single | 21 | Cantilever | 1 | 0.25 Ám | 10 Áin | Right Angle Through Hole | Non Specified - Single Edge | Copper Alloy | 3.18 mm | 0.125 in | 125 °C | -40 C | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Solder |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 21 | Single | 21 | Cantilever | 1 | 0.25 Ám | 10 Áin | Through Hole | Non Specified - Single Edge | Copper Alloy | 3.18 mm | 0.125 in | 125 °C | -40 C | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Solder |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 21 | Single | 21 | Cantilever | 1 | 0.25 Ám | 10 Áin | Through Hole | Non Specified - Single Edge | Copper Alloy | 3.18 mm | 0.125 in | 125 °C | -40 C | 0.156 " | 3.96 mm | Solder | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 21 | Single | 21 | Cantilever | 1 | 0.25 Ám | 10 Áin | Right Angle Through Hole | Non Specified - Single Edge | Copper Alloy | 3.18 mm | 0.125 in | 125 °C | -40 C | 0.128 " | 3.25 mm | Solder | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 21 | Single | 21 | Cantilever | 1 | 0.25 Ám | 10 Áin | Right Angle Through Hole | Non Specified - Single Edge | Copper Alloy | 3.18 mm | 0.125 in | 125 °C | -40 C | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Solder |
