181-044 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB HD RCPT 44P R/A SLDR
| Part | Color | Voltage Rating | Contact Material | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Backset Spacing | Backset Spacing | Shell Material, Finish | Termination | Material Flammability Rating | Current Rating (Amps) | Number of Positions | Connector Type | Number of Rows [custom] | Flange Feature | Contact Finish | Shell Size, Connector Layout | Mounting Type | Connector Style | Features | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Black | 250 V | Brass | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Signal | 8.89 mm | 0.35 in | Nickel Plated Steel | Solder | UL94 V-0 | 3 A | 44 | Receptacle Female Sockets | 3 | 4-40 Mating Side Female Screwlock | Gold | 3 | Panel Mount Right Angle Through Hole | D-Sub High Density | Board Lock Shielded | Flash | |
 NorComp Inc. | Black | 250 V | Brass | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Signal | 8.89 mm | 0.35 in | Nickel Plated Steel | Solder | UL94 V-0 | 3 A | 44 | Plug Male Pins | 3 | Housing/Shell | Gold | 3 | Panel Mount Right Angle Through Hole | D-Sub High Density | Ground Strap Grounding Indents Shielded | Flash | 4-40 |
 NorComp Inc. | Black | Brass | Polybutylene Terephthalate (PBT) | -50 °C | 100 °C | Signal | 8.89 mm | 0.35 in | Solder | UL94 V-0 | 2 A | 44 | Receptacle Female Sockets | 3 | Housing/Shell | Gold | 3 | Panel Mount Right Angle Through Hole | D-Sub High Density | Ground Strap | Flash | 4-40 | ||
 NorComp Inc. | Black | 250 V | Brass | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Signal | 8.89 mm | 0.35 in | Nickel Plated Steel | Solder | UL94 V-0 | 3 A | 44 | Receptacle Female Sockets | 3 | Housing/Shell | Gold | 3 | Panel Mount Right Angle Through Hole | D-Sub High Density | Board Lock Shielded | Flash | 4-40 |
