CF10 Series
Manufacturer: Igus
Beta
⌘K
CABLE 5COND 17AWG GRAY SHLD FEET
| Part | Shield Coverage | Shield Material | Wire Gauge | Length | Jacket Color | Shield Type | Usage | Number of Conductors | Jacket (Insulation) Diameter | Jacket (Insulation) Diameter | Features | Cable Type | Jacket (Insulation) Material | Conductor Material | Conductor Insulation | Conductor Insulation | Voltage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Spool Size [x] | Spool Size [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Igus | 90 % 100 % | Aluminum Copper Tinned | 17 AWG | Enter Number of Feet in Order Quantity | Gray | Braid Foil | Industrial Control | 5 | 0.413 " | 10.49 mm | Abrasion Resistant Flame Retardant Oil Resistant Rip Cord | Multi-Conductor | Thermoplastic Elastomer (TPE) | Copper Bare | TPE | Thermoplastic Elastomer | 1 kV | ||||
Igus | 90 % 100 % | Aluminum Copper Tinned | 17 AWG | Enter Number of Feet in Order Quantity | Gray | Braid Foil | Industrial Control | 4 | Abrasion Resistant Flame Retardant Oil Resistant Rip Cord | Multi-Conductor | Thermoplastic Elastomer (TPE) | Copper Bare | TPE | Thermoplastic Elastomer | 1 kV | 0.394 in | 10.01 mm | ||||
Igus | 90 % 100 % | Aluminum Copper Tinned | 17 AWG | Enter Number of Feet in Order Quantity | Gray | Braid Foil | Industrial Control | 3 | Abrasion Resistant Flame Retardant Oil Resistant Rip Cord | Multi-Conductor | Thermoplastic Elastomer (TPE) | Copper Bare | TPE | Thermoplastic Elastomer | 1 kV | 0.354 " | 8.99 mm | ||||
 Igus | 90 % 100 % | Aluminum Copper Tinned | 26 AWG | Enter Number of Feet in Order Quantity | Blue | Braid | Industrial Control | 12 | Abrasion Resistant Oil Resistant Rip Cord UV Resistant | Multi-Conductor | Thermoplastic Elastomer (TPE) | Copper Bare | TPE | Thermoplastic Elastomer | 500 V | 304.8 m | 1000 ft | ||||
Igus | 90 % 100 % | Aluminum Copper Tinned | 17 AWG | Enter Number of Feet in Order Quantity | Blue | Braid | Industrial Control | 18 | Abrasion Resistant Oil Resistant Rip Cord UV Resistant | Multi-Conductor | Thermoplastic Elastomer (TPE) | Copper Bare | TPE | Thermoplastic Elastomer | 500 V | 0.61 in | 15.49 mm | ||||
Igus | 90 % 100 % | Aluminum Copper Tinned | 14.5 AWG | Enter Number of Feet in Order Quantity | Blue | Braid | Industrial Control | 4 | 0.433 " | 11 mm | Abrasion Resistant Oil Resistant Rip Cord UV Resistant | Multi-Conductor | Thermoplastic Elastomer (TPE) | Copper Bare | TPE | Thermoplastic Elastomer | 500 V | ||||
Igus | 90 % 100 % | Aluminum Copper Tinned | 20 AWG | Enter Number of Feet in Order Quantity | Blue | Braid Foil | Industrial Control | 18 | Abrasion Resistant Oil Resistant Rip Cord UV Resistant | Multi-Conductor | Thermoplastic Elastomer (TPE) | Copper Bare | TPE | Thermoplastic Elastomer | 500 V | 0.531 in | 13.49 mm | ||||
Igus | 90 % 100 % | Aluminum Copper Tinned | 22 AWG | Enter Number of Feet in Order Quantity | Blue | Braid | Industrial Control | 5 | Abrasion Resistant Oil Resistant Rip Cord UV Resistant | Multi-Conductor | Thermoplastic Elastomer (TPE) | Copper Bare | TPE | Thermoplastic Elastomer | 500 V | 0.276 in | 7.01 mm | 304.8 m | 1000 ft | ||
Igus | 90 % 100 % | Aluminum Copper Tinned | 17 AWG | Enter Number of Feet in Order Quantity | Gray | Braid Foil | Industrial Control | 7 | Abrasion Resistant Flame Retardant Oil Resistant Rip Cord | Multi-Conductor | Thermoplastic Elastomer (TPE) | Copper Bare | TPE | Thermoplastic Elastomer | 1 kV | 0.472 " | 11.99 mm | ||||
Igus | 90 % 100 % | Aluminum Copper Tinned | 18 AWG | Enter Number of Feet in Order Quantity | Gray | Braid Foil | Industrial Control | 5 | Abrasion Resistant Flame Retardant Oil Resistant Rip Cord | Multi-Conductor | Thermoplastic Elastomer (TPE) | Copper Bare | TPE | Thermoplastic Elastomer | 1 kV | 0.394 in | 10.01 mm |
