MSM22-NX Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
MSM 22, METAL SWITCH, 10 A SWITC
| Part | Electrical Life | Mechanical Life | Switch Function | Actuator Marking | Color - Actuator/Cap | Type | Termination Style | Operating Temperature [Max] | Operating Temperature [Min] | Circuit | Current Rating (Amps) | Illumination Voltage (Nominal) | Ingress Protection | Mounting Type | Actuator Type | Voltage Rating - AC | Panel Cutout Dimensions [diameter] | Illumination Type, Color | Voltage Rating - DC | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | 50000 Cycles | 1500000 Cycles | On-Mom | No Marking | Silver | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 85 °C | -25 °C | SPDT | 10 A | 24 V | IP40 | Panel Mount Front | Button Flush Round | 250 V | 22.1 mm | Blue LED | ||
 SCHURTER Inc. | 200000 Cycles | 1500000 Cycles | On-Mom | No Marking | Silver | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 85 °C | -25 °C | DPDT | 5 A | 24 V | IP40 | Panel Mount Front | Button Flush Round | 125 V | 22.1 mm | Blue LED | ||
 SCHURTER Inc. | 200000 Cycles | 1500000 Cycles | On-Mom | No Marking | Silver | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 85 °C | -25 °C | SPDT | 100 mA | 24 V | IP40 | Panel Mount Front | Button Flush Round | 22.1 mm | Green LED | 30 V | ||
 SCHURTER Inc. | 200000 Cycles | 1500000 Cycles | On-Mom | No Marking | Silver | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 85 °C | -25 °C | SPDT | 5 A | 24 V | IP40 | Panel Mount Front | Button Flush Round | 125 V | 22.1 mm | Green LED | ||
 SCHURTER Inc. | 200000 Cycles | 1500000 Cycles | On-Mom | No Marking | Silver | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 85 °C | -25 °C | DPDT | 5 A | 24 V | IP40 | Panel Mount Front | Button Flush Round | 125 V | 22.1 mm | Green LED | ||
 SCHURTER Inc. | 50000 Cycles | 1500000 Cycles | On-Mom | No Marking | Silver | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 85 °C | -25 °C | SPDT | 10 A | 24 V | IP40 | Panel Mount Front | Button Flush Round | 250 V | 22.1 mm | LED Red | ||
 SCHURTER Inc. | 200000 Cycles | 1500000 Cycles | On-Mom | No Marking | Silver | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 85 °C | -25 °C | SPDT | 100 mA | 24 V | IP40 | Panel Mount Front | Button Flush Round | 22.1 mm | Blue Green LED Red | 30 V | ||
 SCHURTER Inc. | 50000 Cycles | 1500000 Cycles | On-Mom | No Marking | Clear | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 85 °C | -25 °C | SPDT | 10 A | 24 V | IP40 | Panel Mount Front | Button Flush Round | 250 V | 22.1 mm | Blue Green LED Red | Ceramic Actuator | |
 SCHURTER Inc. | 200000 Cycles | 1500000 Cycles | On-Mom | No Marking | Silver | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 85 °C | -25 °C | SPDT | 100 mA | 24 V | IP40 | Panel Mount Front | Button Flush Round | 22.1 mm | Blue LED | 30 V | ||
 SCHURTER Inc. | 200000 Cycles | 1500000 Cycles | On-Mom | No Marking | Silver | Anti-Vandal Illuminated | Quick Connect - 0.110" (2.8mm) | 85 °C | -25 °C | SPDT | 5 A | 24 V | IP40 | Panel Mount Front | Button Flush Round | 125 V | 22.1 mm | LED Red |
