10087452 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN HEADER R/A 10POS 2.54MM
| Part | Insulation Material | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Pitch - Mating | Pitch - Mating | Termination | Contact Length - Mating | Contact Length - Mating | Number of Positions | Connector Type | Contact Finish - Post | Number of Positions Loaded | Material Flammability Rating | Insulation Height | Insulation Height | Number of Rows | Current Rating (Amps) | Contact Shape | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Mounting Type | Insulation Color | Shrouding | Contact Length - Post | Contact Length - Post | Contact Finish - Mating | Contact Type | Fastening Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Thermoplastic | 0.76 Ám | 30 Áin | 0.1 " | 2.54 mm | Press-Fit Solder | 3.5 mm | 0.138 in | 10 | Header Breakaway | Tin | All | UL94 V-0 | 0.1 in | 2.54 mm | 1 | 3 A | Square | -65 ░C | 125 °C | Copper Alloy | Right Angle Through Hole | Black | Unshrouded | 4.45 mm | 0.175 in | Gold GXT™ | Male Pin | Push-Pull |
 Amphenol ICC (FCI) | Thermoplastic | 0.76 Ám | 30 Áin | 0.1 " | 2.54 mm | Press-Fit Solder | 3.5 mm | 0.138 in | 2 | Header Breakaway | Tin | All | UL94 V-0 | 0.1 in | 2.54 mm | 1 | 3 A | Square | -65 ░C | 125 °C | Copper Alloy | Right Angle Through Hole | Black | Unshrouded | 4.45 mm | 0.175 in | Gold GXT™ | Male Pin | Push-Pull |
