117-93 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN IC DIP SOCKET 48POS GOLD
| Part | Material Flammability Rating | Termination Post Length | Termination Post Length | Current Rating (Amps) | Termination | Contact Finish - Mating | Number of Positions or Pins (Grid) [y] | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) [x] | Type | Type | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Pitch - Mating | Pitch - Mating | Contact Material - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Finish - Post | Contact Material - Post | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Pitch - Post | Pitch - Post | Housing Material | Features | Type [custom] | Type [custom] | Number of Positions or Pins (Grid) | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) [custom] | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | UL94 V-0 | 0.125 in | 3.18 mm | 3 A | Solder | Gold | 2 | 48 | 24 | 0.4 in | DIP | Through Hole | -55 C | 125 °C | 0.07 in | 1.78 mm | Beryllium Copper | 0.76 Ám | 30 Áin | Tin-Lead | Brass Alloy | 200 µin | 5.08 µm | 0.07 in | 1.78 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Open Frame | ||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | 0.125 in | 3.18 mm | 3 A | Solder | Gold | DIP | Through Hole | -55 C | 125 °C | 0.07 in | 1.78 mm | Beryllium Copper | 0.76 Ám | 30 Áin | Tin-Lead | Brass Alloy | 200 µin | 5.08 µm | 0.07 in | 1.78 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Open Frame | 15.24 mm | 0.6 in | 56 | |||||||
Mill-Max Manufacturing Corp. | UL94 V-0 | 0.125 in | 3.18 mm | 3 A | Solder | Gold | DIP | Through Hole | -55 C | 125 °C | 0.07 in | 1.78 mm | Beryllium Copper | 0.76 Ám | 30 Áin | Tin-Lead | Brass Alloy | 200 µin | 5.08 µm | 0.07 in | 1.78 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Open Frame | 15.24 mm | 0.6 in | ||||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | 0.125 in | 3.18 mm | 3 A | Solder | Gold | 0.4 in | DIP | Through Hole | -55 C | 125 °C | 0.07 in | 1.78 mm | Beryllium Copper | 0.76 Ám | 30 Áin | Tin-Lead | Brass Alloy | 200 µin | 5.08 µm | 0.07 in | 1.78 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Open Frame | 30 | 15 | 2 | ||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | 0.125 in | 3.18 mm | 3 A | Solder | Gold | DIP | Through Hole | -55 C | 125 °C | 0.07 in | 1.78 mm | Beryllium Copper | 0.76 Ám | 30 Áin | Tin-Lead | Brass Alloy | 200 µin | 5.08 µm | 0.07 in | 1.78 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Open Frame | 15.24 mm | 0.6 in | 56 | |||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | 0.125 in | 3.18 mm | 3 A | Solder | Gold | 32 | 2 | 0.75 in | DIP | Through Hole | -55 C | 125 °C | 0.07 in | 1.78 mm | Beryllium Copper | 0.76 Ám | 30 Áin | Tin-Lead | Brass Alloy | 200 µin | 5.08 µm | 0.07 in | 1.78 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Closed Frame | 64 | 19.05 mm | |||||
Mill-Max Manufacturing Corp. | UL94 V-0 | 0.125 in | 3.18 mm | 3 A | Solder | Gold | 0.4 in | DIP | Through Hole | -55 C | 125 °C | 0.07 in | 1.78 mm | Beryllium Copper | 0.76 Ám | 30 Áin | Tin-Lead | Brass Alloy | 200 µin | 5.08 µm | 0.07 in | 1.78 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Open Frame | 30 | 15 | 2 | ||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | 0.125 in | 3.18 mm | 3 A | Solder | Gold | DIP | Through Hole | -55 C | 125 °C | 0.07 in | 1.78 mm | Beryllium Copper | 0.76 Ám | 30 Áin | Tin-Lead | Brass Alloy | 200 µin | 5.08 µm | 0.07 in | 1.78 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Open Frame | 15.24 mm | 0.6 in | ||||||||
Mill-Max Manufacturing Corp. | UL94 V-0 | 0.125 in | 3.18 mm | 3 A | Solder | Gold | 32 | 2 | 0.75 in | DIP | Through Hole | -55 C | 125 °C | 0.07 in | 1.78 mm | Beryllium Copper | 0.76 Ám | 30 Áin | Tin-Lead | Brass Alloy | 200 µin | 5.08 µm | 0.07 in | 1.78 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Closed Frame | 64 | 19.05 mm | |||||
Mill-Max Manufacturing Corp. | UL94 V-0 | 0.125 in | 3.18 mm | 3 A | Solder | Gold | 32 | 2 | DIP | Through Hole | -55 C | 125 °C | 0.07 in | 1.78 mm | Beryllium Copper | 0.76 Ám | 30 Áin | Tin-Lead | Brass Alloy | 200 µin | 5.08 µm | 0.07 in | 1.78 mm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Open Frame | 15.24 mm | 0.6 in | 64 |
