1800B Series
Manufacturer: Belden Inc.
Beta
⌘K
#24 FHDPE FS PR PVC
| Part | Shield Material | Shield Coverage | Jacket Color | Number of Conductors | Features | Voltage | Ratings | Cable Type | Conductor Strand [custom] | Conductor Strand [custom] | Length | Length | Wire Gauge | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Conductor Insulation | Usage | Jacket (Insulation) Material | Conductor Material | Operating Temperature [Min] | Operating Temperature [Max] | Shield Type | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum Polyester | 100 % | Violet | 2 | Drain Wire | 300 VDC | UL Style CMR | Multi-Conductor | 7 | 32 AWG | 304.8 m | 1000 ft | 24 AWG | 0.584 mm | 0.023 in | Foam Polyethylene (FPE) | Audio | Poly-Vinyl Chloride (PVC) | Copper Tinned | -30 ░C | 60 °C | Foil | 0.185 in | 4.7 mm |
 Belden Inc. | Aluminum Polyester | 100 % | Gray | 2 | Drain Wire | 300 VDC | UL Style CMR | Multi-Conductor | 7 | 32 AWG | 152.4 m | 500 ft | 24 AWG | 0.584 mm | 0.023 in | Foam Polyethylene (FPE) | Audio | Poly-Vinyl Chloride (PVC) | Copper Tinned | -30 ░C | 60 °C | Foil | 0.185 in | 4.7 mm |
 Belden Inc. | Aluminum Polyester | 100 % | Gray | 2 | Drain Wire | 300 VDC | UL Style CMR | Multi-Conductor | 7 | 32 AWG | 304.8 m | 1000 ft | 24 AWG | 0.584 mm | 0.023 in | Foam Polyethylene (FPE) | Audio | Poly-Vinyl Chloride (PVC) | Copper Tinned | -30 ░C | 60 °C | Foil | 0.185 in | 4.7 mm |
Belden Inc. | Aluminum Polyester | 100 % | Violet | 2 | Drain Wire | 300 VDC | UL Style CMR | Multi-Conductor | 7 | 32 AWG | 304.8 m | 1000 ft | 24 AWG | 0.584 mm | 0.023 in | Foam Polyethylene (FPE) | Audio | Poly-Vinyl Chloride (PVC) | Copper Tinned | -30 ░C | 60 °C | Foil | 0.185 in | 4.7 mm |
