APSC Series
Power Inductors - SMD Chilisin Power - Inductor (IND) Ferrite SMD Shielded Type
Manufacturer: Pulse Electronics
Catalog
Power Inductors - SMD Chilisin Power - Inductor (IND) Ferrite SMD Shielded Type
Beta
⌘K
Power Inductors - SMD Chilisin Power - Inductor (IND) Ferrite SMD Shielded Type
Power Inductors - SMD Chilisin Power - Inductor (IND) Ferrite SMD Shielded Type
Power Inductors - SMD Chilisin Power - Inductor (IND) Ferrite SMD Shielded Type
| Part | Operating Temperature (Max) | Operating Temperature (Min) | Size / Dimension Length | Size / Dimension Width | Mounting Type | Inductance | Current Rating | Height - Seated (Max) | DC Resistance (DCR) (Max) | Inductance Frequency - Test | Tolerance | Current - Saturation (Isat) | Package / Case | Type | Ratings | Material - Core | Shielding |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pulse Electronics | 125 °C | -40 °C | 0.185 in | 0.185 in | Surface Mount | 2.2 µH | 4.3 A | 0.157 in | 33 mOhm | 100 kHz | 30 % | 3.5 A | Nonstandard | Drum Core Wirewound | AEC-Q200 | Ferrite | Shielded |
Pulse Electronics | 125 °C | -40 °C | 0.492 in | 0.492 in | Surface Mount | 18 µH | 0.177 in | 57 mOhm | 100 kHz | 20 % | 4 A | Nonstandard | Drum Core Wirewound | AEC-Q200 | Ferrite | Shielded | |
Pulse Electronics | 125 °C | -40 °C | 0.492 in | 0.492 in | Surface Mount | 120 µH | 0.177 in | 380 mOhm | 100 kHz | 20 % | 1.1 A | Nonstandard | Drum Core Wirewound | AEC-Q200 | Ferrite | Shielded | |
 Pulse Electronics | 125 °C | -40 °C | 0.492 in | 0.492 in | Surface Mount | 22 µH | 0.315 in | 48 mOhm | 1 kHz | 30 % | 5.8 A | Nonstandard | Drum Core Wirewound | AEC-Q200 | Ferrite | Shielded | |
 Pulse Electronics | 125 °C | -40 °C | 0.185 in | 0.185 in | Surface Mount | 3.9 µH | 0.079 in | 155 mOhm | 7.96 MHz | 30 % | 880 mA | Nonstandard | Drum Core Wirewound | AEC-Q200 | Ferrite | Shielded | |
Pulse Electronics | 125 °C | -40 °C | 0.492 in | 0.492 in | Surface Mount | 180 µH | 0.177 in | 620 mOhm | 100 kHz | 20 % | 0.85 mA | Nonstandard | Drum Core Wirewound | AEC-Q200 | Ferrite | Shielded | |
Pulse Electronics | 125 °C | -40 °C | 0.413 in | 0.406 in | Surface Mount | 22 µH | 0.157 in | 80 mOhm | 100 kHz | 30 % | 2.6 A | Nonstandard | Drum Core Wirewound | AEC-Q200 | Ferrite | Shielded | |
Pulse Electronics | 125 °C | -40 °C | 0.264 in | 0.264 in | Surface Mount | 220 µH | 0.118 in | 1.3 Ohm | 10 kHz | 30 % | 0.27 mA | Nonstandard | Drum Core Wirewound | AEC-Q200 | Ferrite | Shielded | |
Pulse Electronics | 125 °C | -40 °C | 0.492 in | 0.492 in | Surface Mount | 82 µH | 0.177 in | 260 mOhm | 100 kHz | 20 % | 1.3 A | Nonstandard | Drum Core Wirewound | AEC-Q200 | Ferrite | Shielded | |
Pulse Electronics | 125 °C | -40 °C | 0.492 in | 0.492 in | Surface Mount | 33 µH | 0.177 in | 97 mOhm | 100 kHz | 20 % | 2.7 A | Nonstandard | Drum Core Wirewound | AEC-Q200 | Ferrite | Shielded |
