KTPS120 Series

Catalog

AC/DC DESKTOP ADAPTER 30V 120W

Part	Applications	Input Type	Operating Temperature [Max]	Voltage - Output	Cord Length	Cord Length	Power (Watts)	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Efficiency	Voltage - Input [Min]	Voltage - Input [Max]	Current - Output (Max) [Max]	Region Utilized	Approval Agency	Form	Standard Number	Current - Output (Max)	Polarization	Output Connector [diameter]	Output Connector [x]	Output Connector
Volgen + Furuno KTPS120-30040-VI	ITE (Commercial)	Cord (Sold Separately)	40 °C	30 V	1 m	39.4 in	120 W	1.54 in	2.6 in	39 mm	66 mm	168.1 mm	6.62 in	Level VI	100 VAC	240 VAC	4 A	International	CB CE cUL GS PSE UL	Desktop (Class I)
Volgen + Furuno KTPS120-24050-VI	ITE (Commercial)	Cord (Sold Separately)	40 °C	24 V	1 m	39.4 in	120 W	1.54 in	2.6 in	39 mm	66 mm	168.1 mm	6.62 in	Level VI	100 VAC	240 VAC		International	IEC	Desktop (Class I)	62368-1	5 A
Volgen + Furuno KTPS120-18066-VI	ITE (Commercial)	Cord (Sold Separately)	40 °C	18 V	1 m	39.4 in	120 W	1.54 in	2.6 in	39 mm	66 mm	168.1 mm	6.62 in	Level VI	100 VAC	240 VAC	6.3 A	International	CB CE cUL GS PSE UL	Desktop (Class I)
Volgen + Furuno KTPS120-15080-VI	ITE (Commercial)	Cord (Sold Separately)	40 °C	15 V	1 m	39.4 in	120 W	1.54 in	2.6 in	39 mm	66 mm	168.1 mm	6.62 in	Level VI	100 VAC	240 VAC	8 A	International	CB CE cUL GS PSE UL	Desktop (Class I)
Volgen + Furuno KTPS120-24050-VI-P2	ITE (Commercial)	Cord (Sold Separately)	40 °C	24 V	1 m	39.4 in	120 W	1.54 in	2.6 in	39 mm	66 mm	168.1 mm	6.62 in	Level VI	100 VAC	240 VAC		International	IEC	Desktop (Class I)	62368-1	5 A	Positive Center	2.5 mm 5.5 mm	9.5 mm	Barrel Plug
