896-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 25POS 0.125
| Part | Termination Rows | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Contact Material | Color | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Card Thickness [Max] | Card Thickness [Min] | Card Type | Mounting Type | Contact Type | Number of Positions | Termination | Number of Positions/Bay/Row | Number of Rows | Pitch | Pitch | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Gold | Copper Alloy | Black | 3.25 mm | 0.128 " | Single | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Through Hole | Cantilever | 25 | Wire Wrap | 25 | 1 | 3.18 mm | 0.125 in | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Gold | Copper Alloy | Black | 3.25 mm | 0.128 " | Single | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Through Hole | Cantilever | 25 | Wire Wrap | 25 | 1 | 3.18 mm | 0.125 in | Flush Mount Side Opening Unthreaded |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Gold | Copper Alloy | Black | 3.25 mm | 0.128 " | Single | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Through Hole | Cantilever | 25 | Solder | 25 | 1 | 3.18 mm | 0.125 in | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Gold | Copper Alloy | Black | Single | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Through Hole | Cantilever | 25 | Wire Wrap | 25 | 1 | 3.18 mm | 0.125 in | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Gold | Copper Alloy | Black | 3.25 mm | 0.128 " | Single | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Through Hole | Cantilever | 25 | Wire Wrap | 25 | 1 | 3.18 mm | 0.125 in | Side Mount Opening Unthreaded |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Gold | Copper Alloy | Black | Single | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Through Hole | Cantilever | 25 | Wire Wrap | 25 | 1 | 3.18 mm | 0.125 in | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Gold | Copper Alloy | Black | 3.25 mm | 0.128 " | Single | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Right Angle Through Hole | Cantilever | 25 | Solder | 25 | 1 | 3.18 mm | 0.125 in | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Gold | Copper Alloy | Black | 2.95 mm | 0.116 " | Single | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Right Angle Through Hole | Cantilever | 25 | Solder | 25 | 1 | 3.18 mm | 0.125 in | Floating Bobbin Flush Mount |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Gold | Copper Alloy | Black | Single | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Through Hole | Cantilever | 25 | Solder | 25 | 1 | 3.18 mm | 0.125 in | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Gold | Copper Alloy | Black | Single | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Through Hole | Cantilever | 25 | Wire Wrap | 25 | 1 | 3.18 mm | 0.125 in | M3 Threaded Insert Top Mount Opening |
