XM3C Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
CONN D-SUB PLUG 25POS R/A SLDR
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Contact Material | Color | Dielectric Material | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Material Flammability Rating | Mounting Type | Number of Rows [custom] | Termination | Shell Material, Finish | Flange Feature | Contact Finish | Contact Type | Features | Connector Style | Connector Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Current Rating (Amps) | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | -55 C | 105 ░C | 300 VDC | Phosphor Bronze | Black | Polybutylene Terephthalate (PBT) Glass Filled | B DB | 3 | UL94 V-0 | Right Angle Through Hole | 2 | Solder | Nickel Plated Steel | Housing/Shell (Unthreaded) | Gold | Signal | Shielded | D-Sub | Plug Male Pins | 25 | 16 µin | 0.41 µm | 5 A | |||
 Omron Electronics Inc-EMC Div | -55 C | 105 ░C | 300 VDC | Phosphor Bronze | Black | Polybutylene Terephthalate (PBT) Glass Filled | UL94 V-0 | Panel Mount Right Angle Through Hole | 2 | Solder | Nickel Plated Steel | 4-40 Mating Side Female Screwlock | Gold | Signal | Board Lock Shielded | D-Sub | Plug Male Pins | 9 | 16 µin | 0.41 µm | 5 A | 1 | DE E | |||
Omron Electronics Inc-EMC Div | -55 C | 105 ░C | 300 VDC | Phosphor Bronze | Black | Polybutylene Terephthalate (PBT) Glass Filled | DC C | UL94 V-0 | Panel Mount Right Angle Through Hole | 2 | Solder | Nickel Plated Steel | 4-40 Mating Side Female Screwlock | Gold | Signal | Board Lock Shielded | D-Sub | Plug Male Pins | 37 | 16 µin | 0.41 µm | 5 A | 4 | |||
 Omron Electronics Inc-EMC Div | -55 C | 105 ░C | 300 VDC | Phosphor Bronze | Black | Polybutylene Terephthalate (PBT) Glass Filled | UL94 V-0 | Panel Mount Right Angle Through Hole | 2 | Solder | Nickel Plated Steel | Housing/Shell (Unthreaded) | Gold | Signal | Board Lock Shielded | D-Sub | Plug Male Pins | 15 | 16 µin | 0.41 µm | 5 A | 2 | ||||
 Omron Electronics Inc-EMC Div | -55 C | 105 ░C | 300 VDC | Phosphor Bronze | Black | Polybutylene Terephthalate (PBT) Glass Filled | DC C | UL94 V-0 | Panel Mount Right Angle Through Hole | 2 | Solder | Nickel Plated Steel | Gold | Signal | Board Lock Shielded | D-Sub | Plug Male Pins | 37 | 16 µin | 0.41 µm | 5 A | 4 | ||||
Omron Electronics Inc-EMC Div | -55 C | 105 ░C | 300 VDC | Phosphor Bronze | Black | Polybutylene Terephthalate (PBT) Glass Filled | B DB | 3 | UL94 V-0 | Panel Mount Right Angle Through Hole | 2 | Solder | Nickel Plated Steel | 4-40 Mating Side Female Screwlock | Gold | Signal | Board Lock Shielded | D-Sub | Plug Male Pins | 25 | 16 µin | 0.41 µm | 5 A | |||
 Omron Electronics Inc-EMC Div | -25 °C | 105 ░C | 300 VDC | Phosphor Bronze | Black | Polybutylene Terephthalate (PBT) Glass Filled | UL94 V-0 | Panel Mount Right Angle Through Hole | 2 | Solder | Nickel Plated Steel | Gold | Signal | Shielded | D-Sub | Plug Male Pins | 9 | 16 µin | 0.41 µm | 3 A | 1 | DE E | ||||
Omron Electronics Inc-EMC Div | -55 C | 105 ░C | 300 VDC | Phosphor Bronze | Black | Polybutylene Terephthalate (PBT) Glass Filled | UL94 V-0 | Right Angle Through Hole | 2 | Solder | Nickel Plated Steel | Housing/Shell (Unthreaded) | Gold | Signal | Shielded | D-Sub | Plug Male Pins | 9 | 16 µin | 0.41 µm | 5 A | 1 | DE E |
