HDF-V44 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB HD PLUG 44POS PNL MNT
| Part | Color | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Number of Positions | Contact Finish Thickness | Number of Rows [custom] | Features | Shell Size, Connector Layout | Contact Finish | Flange Feature | Shell Material, Finish | Connector Type | Ingress Protection | Contact Type | Mounting Type | Termination | Connector Style | Material Flammability Rating | Current Rating (Amps) | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Black | Brass | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) | 44 | Flash | 3 | Grounding Indents | 3 | Gold | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | Plug Male Pins | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | Solder | D-Sub High Density | UL94 V-0 | 3 A | ||
 NorComp Inc. | Black | Brass | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) | 44 | Flash | 3 | Board Lock | 3 | Gold | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | Receptacle Female Sockets | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | Solder | D-Sub High Density | UL94 V-0 | 3 A | ||
 NorComp Inc. | Black | Brass | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) | 44 | Flash | 3 | Board Lock Grounding Indents | 3 | Gold | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | Plug Male Pins | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | Solder | D-Sub High Density | UL94 V-0 | 3 A | ||
NorComp Inc. | Black | Brass | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) | 44 | 3 | Board Lock Grounding Indents | 3 | Gold | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | Plug Male Pins | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | Solder | D-Sub High Density | UL94 V-0 | 3 A | 30 Áin | 0.76 Ám | |
NorComp Inc. | Black | Brass | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) | 44 | 3 | Board Lock | 3 | Gold | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | Receptacle Female Sockets | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | Solder | D-Sub High Density | UL94 V-0 | 3 A | 30 Áin | 0.76 Ám | |
 NorComp Inc. | Black | Brass | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) | 44 | Flash | 3 | 3 | Gold | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | Receptacle Female Sockets | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | Solder | D-Sub High Density | UL94 V-0 | 3 A | |||
NorComp Inc. | Black | Brass | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) | 44 | 3 | Grounding Indents | 3 | Gold | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | Plug Male Pins | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | Solder | D-Sub High Density | UL94 V-0 | 3 A | 30 Áin | 0.76 Ám |
