3400 Series
Manufacturer: E-T-A
Beta
⌘K
CIRCUIT BREAKERS SINGLE POLE THERMAL-MAGNETIC CIRCUIT BREAKERS WITH TEASE-FREE, TRIP-FREE, PRESS-TO-RESET, SNAP ACTION MECHANISM (R-TYPE TM CBE TO EN 60934; M-TYPE WITH MANUAL RELEASE (-H). AVAILABLE WITH FAST ACTING AND STANDARD MAGNETIC TRIPPING CHARAC
| Part | Voltage Rating - DC | Mounting Type | Voltage Rating - AC | Current Rating (Amps) | Breaker Type | Illumination | Actuator Type | Approval Agency | Number of Poles |
|---|---|---|---|---|---|---|---|---|---|
80 V | Panel Mount | 250 V | 10 A | Thermal Magnetic | None | Push to Reset | CSA C22.2 No 235 IEC 60934 UL1077 | 1 | |
 E-T-A | 80 V | Panel Mount | 250 V | 3 A | Thermal Magnetic | None | Push to Reset | CSA C22.2 No 235 IEC 60934 UL1077 | 1 |
E-T-A | 80 V | Panel Mount | 250 V | 2 A | Thermal Magnetic | None | Push to Reset | CSA C22.2 No 235 IEC 60934 UL1077 | 1 |
E-T-A | 80 V | Panel Mount | 250 V | 5 A | Thermal Magnetic | None | Push-Pull Plunger | CSA C22.2 No 235 IEC 60934 UL1077 | 1 |
E-T-A | 80 V | Panel Mount | 250 V | 5 A | Thermal Magnetic | None | Push-Pull Plunger | CSA C22.2 No 235 IEC 60934 UL1077 | 1 |
 E-T-A | 80 V | Panel Mount | 250 V | 0.5 A | Thermal Magnetic | None | Push to Reset | CSA C22.2 No 235 IEC 60934 UL1077 | 1 |
E-T-A | 80 V | Panel Mount | 250 V | 5 A | Thermal Magnetic | None | Push to Reset | CSA C22.2 No 235 IEC 60934 UL1077 | 1 |
E-T-A | 80 V | Panel Mount | 250 V | 10 A | Thermal Magnetic | None | Push-Pull Plunger | CSA C22.2 No 235 IEC 60934 UL1077 | 1 |
E-T-A | 80 V | Panel Mount | 250 V | 15 A | Thermal Magnetic | None | Push to Reset | CSA C22.2 No 235 IEC 60934 UL1077 | 1 |
