11TL1 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH TOGGLE SPDT 10A 125V
| Part | Actuator Material | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Panel Cutout Dimensions [diameter] | Illumination | Ingress Protection | Current Rating (Amps) | Voltage Rating - AC | Actuator Type | Switch Function | Termination Style | Bushing Thread | Actuator Length [x] | Circuit |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Panel Mount | 12.4 mm | Non-Illuminated | Environment Sealed | 10 A | 125 V | Standard Round | On-Mom | Solder Turret | 15/32-32 | 17.27 mm | SPDT |
 Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Panel Mount | 12.4 mm | Non-Illuminated | Environment Sealed | 15 A | 125 V | Standard Round | On-On | Solder Turret | 15/32-32 | 17.27 mm | SPDT |
 Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Panel Mount | 12.4 mm | Non-Illuminated | Environment Sealed | 10 A | 125 V | Standard Round | On-Off-Mom | Solder Turret | 15/32-32 | 17.27 mm | SPDT |
Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Panel Mount | 12.4 mm | Non-Illuminated | Environment Sealed | 15 A | 125 V | Locking Lever | On-Off-On | Solder Turret | 15/32-32 | 26.67 mm | DPDT |
Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Panel Mount | 12.4 mm | Non-Illuminated | Environment Sealed | 10 A | 125 V | Standard Round | Off-Mom | Solder Turret | 15/32-32 | 17.27 mm | SPST-NO |
Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Panel Mount | 12.4 mm | Non-Illuminated | Environment Sealed | 15 A | 125 V | Locking Lever | On-On | Solder Turret | 15/32-32 | 26.67 mm | SPDT |
Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Panel Mount | 12.4 mm | Non-Illuminated | Environment Sealed | 15 A | 125 V | Locking Lever | On-Off | Solder Turret | 15/32-32 | 26.67 mm | SPST |
 Honeywell Sensing and Productivity Solutions | Nickel Plated | -65 ░C | 71 °C | Panel Mount | 12.4 mm | Non-Illuminated | Environment Sealed | 10 A | 125 V | Standard Round | Mom-Off-Mom | Solder Turret | 15/32-32 | 17.27 mm | SPDT |
