SRU6025A Series

Catalog

IND6.2X6.5X2.5MM,1.2UH30%4A,SHDSMD /TAPE & REEL - 7" REEL

Part	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Mounting Type	Tolerance	Q @ Freq	DC Resistance (DCR)	Inductance	Shielding	Inductance Frequency - Test	Type	Material - Core	Frequency - Self Resonant	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Current Rating (Amps)	Ratings	Current - Saturation (Isat)	DC Resistance (DCR) [Max]	Q @ Freq [custom]	Q @ Freq [custom]
Bourns Inc. SRU6025A-1R2Y	125 °C	-40 C	Nonstandard	Surface Mount	30 %	7.96 MHz 8	19 mOhm	1.2 µH	Shielded	100 kHz	Drum Core Wirewound	Ferrite	120 MHz	0.244 in	0.256 in	6.2 mm	6.5 mm	4 A	AEC-Q200	3.2 A
Bourns Inc. SRU6025A-330Y	125 °C	-40 C	Nonstandard	Surface Mount	30 %			33 µH	Shielded	100 kHz	Drum Core Wirewound	Ferrite	12 MHz	0.244 in	0.256 in	6.2 mm	6.5 mm	1.2 A	AEC-Q200	640 mA	180 mOhm	12	2.52 MHz
Bourns Inc. SRU6025A-2R2Y	125 °C	-40 C	Nonstandard	Surface Mount	30 %	7.96 MHz 8	24 mOhm	2.2 µH	Shielded	100 kHz	Drum Core Wirewound	Ferrite	65 MHz	0.244 in	0.256 in	6.2 mm	6.5 mm	3.4 A	AEC-Q200	2.35 A
Bourns Inc. SRU6025A-221Y	125 °C	-40 C	Nonstandard	Surface Mount	30 %			220 µH	Shielded	100 kHz	Drum Core Wirewound	Ferrite	4 MHz	0.244 in	0.256 in	6.2 mm	6.5 mm	0.42 A	AEC-Q200	240 mA	1.25 Ohm	20	796 kHz
Bourns Inc. SRU6025A-151Y	125 °C	-40 C	Nonstandard	Surface Mount	30 %	30 796 kHz	770 mOhm	150 µH	Shielded	100 kHz	Drum Core Wirewound	Ferrite	5 MHz	0.244 in	0.256 in	6.2 mm	6.5 mm	0.54 A	AEC-Q200	280 mA
