895-033 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 33POS 0.100
| Part | Termination Rows | Material - Insulation | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Positions/Bay/Row | Color | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Number of Positions [custom] | Number of Rows | Contact Type | Termination | Read Out | Gender | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Mounting Type | Contact Finish | Card Type | Card Thickness [Max] | Card Thickness [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 33 | Black | 125 °C | -40 C | Copper Alloy | 33 | 1 | Cantilever | Wire Wrap | Single | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Gold | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm | 33 | Black | 125 °C | -40 C | Copper Alloy | 33 | 1 | Cantilever | Solder | Single | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Right Angle Through Hole | Gold | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 4-40 Threaded Insert Top Mount Opening | 33 | Black | 125 °C | -40 C | Copper Alloy | 33 | 1 | Cantilever | Wire Wrap | Single | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Gold | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | 33 | Black | 125 °C | -40 C | Copper Alloy | 33 | 1 | Cantilever | Solder | Single | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Gold | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.128 " | 3.25 mm | 33 | Black | 125 °C | -40 C | Copper Alloy | 33 | 1 | Cantilever | Solder | Single | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Right Angle Through Hole | Gold | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.128 " | 3.25 mm | 33 | Black | 125 °C | -40 C | Copper Alloy | 33 | 1 | Cantilever | Wire Wrap | Single | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Gold | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | M3 Threaded Insert Top Mount Opening | 33 | Black | 125 °C | -40 C | Copper Alloy | 33 | 1 | Cantilever | Wire Wrap | Single | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Gold | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 4-40 Threaded Insert Top Mount Opening | 33 | Black | 125 °C | -40 C | Copper Alloy | 33 | 1 | Cantilever | Wire Wrap | Single | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Gold | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm | 33 | Black | 125 °C | -40 C | Copper Alloy | 33 | 1 | Cantilever | Solder | Single | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Gold | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | 33 | Black | 125 °C | -40 C | Copper Alloy | 33 | 1 | Cantilever | Solder | Single | Female | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Through Hole | Gold | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
