ULS-15 Series

Catalog

ISOLATED SURFACE MOUNT DC/DC CONVERTER, SIXTEENTH BRICK, 2:1, 30 W, 1 OUTPUT, 15 V

Part	Package / Case	Mounting Type	Applications	Efficiency	Type	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Isolation	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Control Features	Voltage - Input (Min) [Min]	Features	Current - Output (Max) [Max]	Voltage - Input (Max) [Max]	Power (Watts)	Number of Outputs
Murata Electronics ULS-15/2-D48NM-C	8-SMD Module 1/16 Brick	Surface Mount	ITE (Commercial)	89 %	Isolated Module	15 V	85 °C	-40 C	2250 VDC	33 mm	1.3 in	0.4 "	22.9 mm	10.2 mm	0.9 in	Active Low Enable	36 V	OTP OVP Remote On/Off SCP UVLO	2 A	75 V	30 Watts	1
Murata Electronics ULS-15/2-D48P-C	8-DIP Module 1/16 Brick	Through Hole	ITE (Commercial)	89 %	Isolated Module	15 V	85 °C	-40 C	2250 VDC	33 mm	1.3 in	0.4 "	22.9 mm	10.2 mm	0.9 in	Active High Enable	36 V	OTP OVP Remote On/Off SCP UVLO	2 A	75 V	30 Watts	1
