5351/9C Series
Manufacturer: ALPHA WIRE
Beta
⌘K
MULTI-PAIR 18COND 20AWG
| Part | Shield Material | Shield Coverage | Conductor Material | Length [x] | Length [x] | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Cable Type | Conductor Insulation | Ratings | Shield Type | Jacket (Insulation) Material | Usage | Voltage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket Color | Number of Conductors | Operating Temperature [Min] | Operating Temperature [Max] | Wire Gauge | Features | Conductor Strand [custom] | Conductor Strand [custom] | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Copper Tinned Suprashield® | 70 % 100 % | Copper Tinned | 100 ft | 30.5 m | 1.6 mm | 0.063 in | Multi-Pair | Poly-Vinyl Chloride (PVC) | ISO 10993 | Braid Foil | Poly-Vinyl Chloride (PVC) | Communication Control | 300 VDC | 11.33 mm | 0.446 in | Slate | 18 | -35 °C | 105 ░C | 20 AWG | Biological Compatibility Drain Wire Rip Cord | 28 AWG | 7 | ||
ALPHA WIRE | Copper Tinned Suprashield® | 70 % 100 % | Copper Tinned | 1.6 mm | 0.063 in | Multi-Pair | Poly-Vinyl Chloride (PVC) | ISO 10993 | Braid Foil | Poly-Vinyl Chloride (PVC) | Communication Control | 300 VDC | 11.33 mm | 0.446 in | Slate | 18 | -35 °C | 105 ░C | 20 AWG | Biological Compatibility Drain Wire Rip Cord | 28 AWG | 7 | 304.8 m | 1000 ft | ||
 ALPHA WIRE | Copper Tinned Suprashield® | 70 % 100 % | Copper Tinned | 1.6 mm | 0.063 in | Multi-Pair | Poly-Vinyl Chloride (PVC) | ISO 10993 | Braid Foil | Poly-Vinyl Chloride (PVC) | Communication Control | 300 VDC | 11.33 mm | 0.446 in | Black | 18 | -35 °C | 105 ░C | 20 AWG | Biological Compatibility Drain Wire Rip Cord | 28 AWG | 7 | 304.8 m | 1000 ft | ||
ALPHA WIRE | Copper Tinned Suprashield® | 70 % 100 % | Copper Tinned | 1.6 mm | 0.063 in | Multi-Pair | Poly-Vinyl Chloride (PVC) | ISO 10993 | Braid Foil | Poly-Vinyl Chloride (PVC) | Communication Control | 300 VDC | 11.33 mm | 0.446 in | Slate | 18 | -35 °C | 105 ░C | 20 AWG | Biological Compatibility Drain Wire Rip Cord | 28 AWG | 7 | 152.4 m | 500 ft |
