E3FB-BN Series

Catalog

SENSOR REFLECTVE 500MM NPN DO/LO

Part	Sensing Distance [Min]	Sensing Distance [Max]	Sensing Distance [Min]	Sensing Distance [Max]	Voltage - Supply [Max]	Voltage - Supply [Min]	Response Time	Ingress Protection	Light Source	Operating Temperature [Max]	Operating Temperature [Min]	Sensing Method	Connection Method	Cable Length	Cable Length
Omron Electronics Inc-EMC Div E3FB-BN21	100 mm	19.685 "	3.937 in	500 mm	30 VDC	10 VDC	500 µs	IEC IP67 IP69K	Red LED	55 °C	-25 °C	Reflective	4POS Connector M12
Omron Electronics Inc-EMC Div E3FB-BN12 2M	100 mm	78.74 "	3.937 in	2000 mm	30 VDC	10 VDC	500 µs	IEC IEC IP67 IP67 IP69K	Red LED	55 °C	-25 °C	Reflective	Cable	78.74 in	2 m
Omron Electronics Inc-EMC Div E3FB-BN22	100 mm	78.74 "	3.937 in	2000 mm	30 VDC	10 VDC	500 µs	IEC IP67 IP69K	Red LED	55 °C	-25 °C	Reflective	4POS Connector M12
