460819 Series

Catalog

HOOK-UP STRND 8AWG GREEN

Part	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Material	Wire Gauge	Jacket (Insulation) Material	Conductor Strand [custom]	Conductor Strand [custom]	Cable Type	Voltage	Jacket Color	Ratings	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length	Length	Length [x]	Length [x]
ALPHA WIRE 460819 GR001	-40 C	105 ░C	Copper Bare	8 AWG	Poly-Vinyl Chloride (PVC)	0.0295 in	19	Hook-Up	600 V	Green	UL Style 1028/1231	1.19 mm	0.047 in	304.8 m	1000 ft
ALPHA WIRE 460819 BL001	-40 C	105 ░C	Copper Bare	8 AWG	Poly-Vinyl Chloride (PVC)	0.0295 in	19	Hook-Up	600 V	Blue	UL Style 1028/1231	1.19 mm	0.047 in	304.8 m	1000 ft
ALPHA WIRE 460819 BK002	-40 C	105 ░C	Copper Bare	8 AWG	Poly-Vinyl Chloride (PVC)	0.0295 in	19	Hook-Up	600 V	Black	UL Style 1028/1231	1.19 mm	0.047 in	152.4 m	500 ft
ALPHA WIRE 460819 GR005	-40 C	105 ░C	Copper Bare	8 AWG	Poly-Vinyl Chloride (PVC)	0.0295 in	19	Hook-Up	600 V	Green	UL Style 1028/1231	1.19 mm	0.047 in			100 ft	30.5 m
ALPHA WIRE 460819 OR001	-40 C	105 ░C	Copper Bare	8 AWG	Poly-Vinyl Chloride (PVC)	0.0295 in	19	Hook-Up	600 V	Orange	UL Style 1028/1231	1.19 mm	0.047 in	304.8 m	1000 ft
ALPHA WIRE 460819 VI001	-40 C	105 ░C	Copper Bare	8 AWG	Poly-Vinyl Chloride (PVC)	0.0295 in	19	Hook-Up	600 V	Violet	UL Style 1028/1231	1.19 mm	0.047 in	304.8 m	1000 ft
ALPHA WIRE 460819 RD002	-40 C	105 ░C	Copper Bare	8 AWG	Poly-Vinyl Chloride (PVC)	0.0295 in	19	Hook-Up	600 V	Red	UL Style 1028/1231	1.19 mm	0.047 in	152.4 m	500 ft
ALPHA WIRE 460819 WH001	-40 C	105 ░C	Copper Bare	8 AWG	Poly-Vinyl Chloride (PVC)	0.0295 in	19	Hook-Up	600 V	White	UL Style 1028/1231	1.19 mm	0.047 in	304.8 m	1000 ft
ALPHA WIRE 460819 OR005	-40 C	105 ░C	Copper Bare	8 AWG	Poly-Vinyl Chloride (PVC)	0.0295 in	19	Hook-Up	600 V	Orange	UL Style 1028/1231	1.19 mm	0.047 in			100 ft	30.5 m
ALPHA WIRE 460819 RD005	-40 C	105 ░C	Copper Bare	8 AWG	Poly-Vinyl Chloride (PVC)	0.0295 in	19	Hook-Up	600 V	Red	UL Style 1028/1231	1.19 mm	0.047 in			100 ft	30.5 m
