042878 Series
Manufacturer: Molex
Beta
⌘K
CONN MOD JACK 4P4C VERT UNSHLD
| Part | Ratings | Features | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Contacts | Mounting Type | Termination | LED Color | Contact Material | Number of Ports | Operating Temperature [Max] | Operating Temperature [Min] | Shielding | Connector Type | Contact Finish | Tab Direction | Orientation | Number of Rows | Number of Positions/Contacts |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | Cat3 | Board Lock Panel Stops | 50 µin | 1.27 µm | 4p4c | Through Hole | Solder | Does Not Contain LED | Phosphor Bronze | 1 | 85 °C | -40 °C | Unshielded | Jack | Gold | User Selectable | Vertical | 1 | |
 Molex | Cat3 | Board Lock Panel Stops | 50 µin | 1.27 µm | 6p6c (RJ11 RJ12 RJ14 RJ25) | Through Hole | Solder | Does Not Contain LED | Phosphor Bronze | 1 | 85 °C | -40 °C | Unshielded | Jack | Gold | User Selectable | Vertical | 1 | |
 Molex | Cat3 | 50 µin | 1.27 µm | 8p8c (RJ45 Ethernet) | Through Hole | Solder | Does Not Contain LED | Phosphor Bronze | 1 | 85 °C | -40 °C | Unshielded | Jack | Gold | User Selectable | Vertical | 1 | ||
 Molex | Cat3 | 50 µin | 1.27 µm | 6p6c (RJ11 RJ12 RJ14 RJ25) | Through Hole | Solder | Does Not Contain LED | Phosphor Bronze | 1 | 85 °C | -40 °C | Unshielded | Jack | Gold | User Selectable | Vertical | 1 | ||
 Molex | Cat3 | Board Lock Keyed | 50 µin | 1.27 µm | 8p8c (RJ45 Ethernet) | Through Hole | Solder | Does Not Contain LED | Phosphor Bronze | 1 | 85 °C | -40 °C | Unshielded | Jack | Gold | User Selectable | Vertical | 1 | |
Molex | Cat3 | Board Lock Panel Stops | 50 µin | 1.27 µm | Through Hole | Solder | Does Not Contain LED | Phosphor Bronze | 1 | 85 °C | -40 °C | Unshielded | Jack | Gold | User Selectable | Vertical | 1 | 2 6 | |
Molex | Cat3 | 50 µin | 1.27 µm | 6p6c (RJ11 RJ12 RJ14 RJ25) | Through Hole | Solder | Does Not Contain LED | Phosphor Bronze | 1 | 85 °C | -40 °C | Unshielded | Jack | Gold | User Selectable | Vertical | 1 | ||
 Molex | Cat3 | 50 µin | 1.27 µm | 8p8c (RJ45 Ethernet) | Through Hole | Solder | Does Not Contain LED | Phosphor Bronze | 1 | 85 °C | -40 °C | Unshielded | Jack | Gold | User Selectable | Vertical | 1 | ||
Molex | Cat3 | Board Lock Keyed | 50 µin | 1.27 µm | 8p2c | Through Hole | Solder | Does Not Contain LED | Phosphor Bronze | 1 | 85 °C | -40 °C | Unshielded | Jack | Gold | User Selectable | Vertical | 1 | |
 Molex | Cat3 | 50 µin | 1.27 µm | 8p10c | Through Hole | Solder | Does Not Contain LED | Phosphor Bronze | 1 | 85 °C | -40 °C | Unshielded | Jack | Gold | User Selectable | Vertical | 1 |
