1825255 Series

Catalog

SWITCH SLIDE SPDT 300MA 125V

Part	Actuator Material	Switch Function	Actuator Type	Contact Finish	Contact Timing	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Electrical Life	Mechanical Life	Actuator Length [x]	Voltage Rating - AC	Termination Style	Features	Circuit	Contact Material	Operating Force	Switch Travel	Voltage Rating - DC
TE Connectivity Raychem Cable Protection 1825255-3	Aluminum	On-On	Baton	Silver	Shorting	300 mA	85 °C	-20 C	Through Hole	15000 Cycles	15000 Cycles	10 mm	125 V	PC Pin	Epoxy Sealed Terminals	SPDT	Copper Alloy	600 gf	4 mm
TE Connectivity Raychem Cable Protection 1825255-5	Polyoxymethylene (Acetal) (POM)	On-Off-On	Standard	Silver	Shorting	300 mA	85 °C	-20 C	Through Hole	15000 Cycles	15000 Cycles	4.5 mm	125 V	PC Pin	Epoxy Sealed Terminals	SPDT	Copper Alloy	600 gf	2 mm
TE Connectivity Raychem Cable Protection 1825255-8	Polyoxymethylene (Acetal) (POM)	On-On-On	Standard	Gold	Shorting	0.4 VA	85 °C	-20 C	Through Hole	15000 Cycles	15000 Cycles	4.5 mm	20 V	PC Pin	Epoxy Sealed Terminals	SP3T	Copper Alloy	600 gf	2 mm	20 V
TE Connectivity Raychem Cable Protection 1825255-1	Polyoxymethylene (Acetal) (POM)	On-On	Standard	Silver	Non-Shorting	300 mA	85 °C	-20 C	Through Hole	15000 Cycles	15000 Cycles	4.5 mm	125 V	PC Pin	Epoxy Sealed Terminals	SPDT	Copper Alloy	600 gf	4 mm
