QS18A Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
WORLD-BEAM QS18 UNIVERSAL VOLT;
| Part | Ingress Protection | Connection Method | Output Configuration | Sensing Method | Adjustment Type | Response Time | Operating Temperature [Min] | Operating Temperature [Max] | Light Source | Sensing Distance | Sensing Distance | Voltage - Supply [Max] | Voltage - Supply [Min] | Cable Length | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Connector | Light-On | Polarized Retroreflective | Adjustable Potentiometer | 8.3 ms | -25 °C | 70 °C | Red (630nm) | 11.48 ft | 350 cm | 270 VDC 270 VAC/DC | 20 VAC 20 VDC | ||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | PNP - Dark-ON/Light-ON | Polarized Retroreflective | Adjustable Potentiometer | 600 µs | -20 ░C | 70 °C | LED | 137.795 in | 350 cm | 30 VDC | 10 VDC | |||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Cable | Polarized Retroreflective | Adjustable Potentiometer | 8.3 ms | -20 ░C | 70 °C | Red (660nm) | 137.795 in | 350 cm | 140 VDC/VAC | 20 VDC/VAC | 78.74 " | 2 m | |
BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Connector | Light-On | Retroreflective NonPolarized | Adjustable Potentiometer | 8.3 ms | -25 °C | 70 °C | Red (630nm) | 21.33 ft | 6.5 m | 140 VAC/DC 140 V | 20 VDC 20 VAC | ||
 BANNER ENGINEERING | IEC IP67 NEMA 6P | Connector | NPN/PNP - Light-ON | Adjustable | 2.5 ms | -20 ░C | 55 °C | Red (630nm) | 7.874 in | 200 mm | 30 VDC | 10 VDC | |||
BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Cable | NPN/PNP - Light-ON | Background Suppression | Adjustable | 2.5 ms | -20 ░C | 55 °C | Red LED | 11.811 " | 30 cm | 30 VDC | 10 VDC | 78.74 " | 2 m |
BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Connector | NPN/PNP - Light-ON | Background Suppression | Adjustable | 2.5 ms | -20 ░C | 55 °C | Red LED | 11.811 " | 30 cm | 30 VDC | 10 VDC |
