306-024 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 56POS 0.156
| Part | Material - Insulation | Termination Rows | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Contact Material | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Termination | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Color | Read Out | Mounting Type | Pitch | Pitch | Contact Type | Gender | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | -40 C | 105 ░C | Non Specified - Dual Edge | Copper Alloy | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 24 | Solder Eyelet(s) | 2 | 0.25 Ám | 10 Áin | Green | Dual | Free Hanging (In-Line) | 3.96 mm | 0.156 in | Cantilever | Female | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Tin | -40 C | 105 ░C | Non Specified - Dual Edge | Copper Alloy | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 24 | Solder | 2 | Green | Dual | Panel Mount Through Hole | 3.96 mm | 0.156 in | Cantilever | Female | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Tin | -40 C | 105 ░C | Non Specified - Dual Edge | Copper Alloy | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 24 | Solder | 2 | Green | Dual | Panel Mount Through Hole | 3.96 mm | 0.156 in | Cantilever | Female | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | -40 C | 105 ░C | Non Specified - Dual Edge | Copper Alloy | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 24 | Solder | 2 | 0.25 Ám | 10 Áin | Green | Dual | Panel Mount Through Hole | 3.96 mm | 0.156 in | Cantilever | Female | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Tin | -40 C | 105 ░C | Non Specified - Dual Edge | Copper Alloy | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 24 | Solder | 2 | Green | Dual | Panel Mount Through Hole | 3.96 mm | 0.156 in | Cantilever | Female | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | -40 C | 105 ░C | Non Specified - Dual Edge | Copper Alloy | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 24 | Solder Eyelet(s) | 2 | 0.25 Ám | 10 Áin | Green | Dual | Panel Mount | 3.96 mm | 0.156 in | Cantilever | Female | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | -40 C | 105 ░C | Non Specified - Dual Edge | Copper Alloy | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 24 | Solder | 2 | 0.25 Ám | 10 Áin | Green | Dual | Panel Mount Through Hole | 3.96 mm | 0.156 in | Cantilever | Female | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | -40 C | 105 ░C | Non Specified - Dual Edge | Copper Alloy | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 24 | Solder Eyelet(s) | 2 | 0.25 Ám | 10 Áin | Green | Dual | Panel Mount | 3.96 mm | 0.156 in | Cantilever | Female | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Tin | -40 C | 105 ░C | Non Specified - Dual Edge | Copper Alloy | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 24 | Solder | 2 | Green | Dual | Panel Mount Through Hole | 3.96 mm | 0.156 in | Cantilever | Female | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Tin | -40 C | 105 ░C | Non Specified - Dual Edge | Copper Alloy | 56 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 24 | Solder Eyelet(s) | 2 | Green | Dual | Panel Mount | 3.96 mm | 0.156 in | Cantilever | Female | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides |
