MGDBK10 Series

Catalog

DC DC CONVERTER

Part	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Applications	Type	Mounting Type	Package / Case	Voltage - Input (Min) [Min]	Voltage - Input (Max) [Max]	Current - Output (Max)	Current - Output (Max)	Efficiency	Voltage - Output 2	Number of Outputs	Features	Power (Watts)	Voltage - Isolation	Voltage - Output 1	Current - Output (Max) [Max]
Gaia Converter MGDBK10DF	-40 C	95 °C	8.2 mm	1.57 in	1.02 in	0.32 "	26 mm	40 mm	ITE (Commercial)	Isolated Module	Through Hole	8-DIP Module 5 Leads	4.5 V	16 V	330 mA	330 mA	80 %	-15 V	2	Remote On/Off	10 W	1.5 kV	15 V
Gaia Converter MGDBK10QE	-40 C	95 °C	8.2 mm	1.57 in	1.02 in	0.32 "	26 mm	40 mm	ITE (Commercial)	Isolated Module	Through Hole	8-DIP Module 4 Leads	36 V	160 V			80 %		1		10 W	1.5 kV	12 V	0.8 A
Gaia Converter MGDBK10DC	-40 C	95 °C	8.2 mm	1.57 in	1.02 in	0.32 "	26 mm	40 mm	ITE (Commercial)	Isolated Module	Through Hole	8-DIP Module 5 Leads	4.5 V	16 V	1 A		80 %	-5 V	2	Remote On/Off	10 W	1.5 kV	5 V
Gaia Converter MGDBK10QC	-40 C	95 °C	8.2 mm	1.57 in	1.02 in	0.32 "	26 mm	40 mm	ITE (Commercial)	Isolated Module	Through Hole	8-DIP Module 4 Leads	36 V	160 V	1 A		80 %	-5 V	2		10 W	1.5 kV	5 V
Gaia Converter MGDBK10QE/Y	-40 C	95 °C	8.2 mm	1.57 in	1.02 in	0.32 "	26 mm	40 mm	ITE (Commercial)	Isolated Module	Through Hole	8-DIP Module 4 Leads	36 V	160 V			80 %		1		10 W	1.5 kV	12 V	0.8 A
