MCIMX7 Series

Manufacturer: Freescale Semiconductor - NXP

Catalog

APPLICATIONS PROCESSOR, ARM CORTEX-A7, I.MX 7DUAL SERIES, 1 GHZ, BGA-541

Part	Security Features	Supplier Device Package	Mounting Type	Core Processor	RAM Controllers	Speed	Voltage - I/O	Ethernet	Ethernet	Operating Temperature [Max]	Operating Temperature [Min]	USB	Package / Case	Additional Interfaces	Co-Processors/DSP	Number of Cores/Bus Width [custom]	Number of Cores/Bus Width [custom]	Number of Cores/Bus Width	Operating System	Board Type	Interconnect System	Utilized IC / Part	Platform	Contents	Type	Display & Interface Controllers
Freescale Semiconductor - NXP MCIMX7D7DVM10SC	A-HAB ARM TZ CAAM CSU SJC SNVS	541-MAPBGA (19x19)	Surface Mount	ARM® Cortex®-A7 ARM® Cortex®-M4	DDR3 DDR3L LPDDR2 LPDDR3	1 GHz	1.8 V 3.3 V	10 Mbps 100 Mbps 1000 Mbps	2	95 °C	0 °C	USB 2.0 + PHY (1) USB 2.0 OTG + PHY (2)	541-LFBGA	AC'97 CAN eCSPI I2C I2S MMC/SD/SDIO PCIe QSPI SAI UART	Multimedia NEON™ MPE	32 Bit	2
Freescale Semiconductor - NXP MCIMX7S5EVK08SC	A-HAB ARM TZ CAAM CSU SJC SNVS	488-TFBGA (12x12)	Surface Mount	ARM® Cortex®-A7 ARM® Cortex®-M4	DDR3 DDR3L LPDDR2 LPDDR3	800 MHz	1.8 V 3.3 V	10 Mbps 100 Mbps 1000 Mbps		105 °C	-20 °C	USB 2.0 + PHY (1) USB 2.0 OTG + PHY (1)	488-TFBGA	AC'97 CAN eCSPI I2C I2S MMC/SD/SDIO PCIe QSPI SAI UART	Multimedia NEON™ MPE			1 Core 32 Bit
Freescale Semiconductor - NXP MCIMX7SABRE			Fixed	ARM® Cortex®-A7															Linux	Evaluation Platform	mikroBUS Click	i.MX 7Dual	SABRE	Board(s)	MPU
Freescale Semiconductor - NXP MCIMX7S3EVK08SD	A-HAB ARM TZ CAAM CSU SJC SNVS	488-TFBGA (12x12)	Surface Mount	ARM® Cortex®-A7 ARM® Cortex®-M4	DDR3 DDR3L LPDDR2 LPDDR3	800 MHz	1.8 V 3.3 V	10 Mbps 100 Mbps 1000 Mbps		105 °C	-20 °C	USB 2.0 + PHY (1) USB 2.0 OTG + PHY (1)	488-TFBGA	AC'97 eCSPI I2C I2S MMC/SD/SDIO PCIe QSPI SAI UART	Multimedia NEON™ MPE			1 Core 32 Bit
Freescale Semiconductor - NXP MCIMX7S3DVK08SC	A-HAB ARM TZ CAAM CSU SJC SNVS	488-TFBGA (12x12)	Surface Mount	ARM® Cortex®-A7 ARM® Cortex®-M4	DDR3 DDR3L LPDDR2 LPDDR3	800 MHz	1.8 V 3.3 V	10 Mbps 100 Mbps 1000 Mbps		95 °C	0 °C	USB 2.0 + PHY (1) USB 2.0 OTG + PHY (1)	488-TFBGA	AC'97 eCSPI I2C I2S MMC/SD/SDIO PCIe QSPI SAI UART	Multimedia NEON™ MPE			1 Core 32 Bit
Freescale Semiconductor - NXP MCIMX7U5DVP08SC
Freescale Semiconductor - NXP MCIMX7S3DVK08SC	A-HAB ARM TZ CAAM CSU SJC SNVS	488-TFBGA (12x12)	Surface Mount	ARM® Cortex®-A7 ARM® Cortex®-M4	DDR3 DDR3L LPDDR2 LPDDR3	800 MHz	1.8 V 3.3 V	10 Mbps 100 Mbps 1000 Mbps		95 °C	0 °C	USB 2.0 + PHY (1) USB 2.0 OTG + PHY (1)	488-TFBGA	AC'97 eCSPI I2C I2S MMC/SD/SDIO PCIe QSPI SAI UART	Multimedia NEON™ MPE			1 Core 32 Bit
Freescale Semiconductor - NXP MCIMX7U3CVP06SC				ARM® Cortex®-A7	LPDDR2 LPDDR3	650 MHz				105 ░C	-40 °C	USB 2.0 (2)		FlexIO GPIO I2C I2S SPI UART	ARM® Cortex®-M4			1 Core 32 Bit								MIPI-DSI
Freescale Semiconductor - NXP MCIMX7D2DVK12SC	A-HAB ARM TZ CAAM CSU SJC SNVS	488-TFBGA (12x12)	Surface Mount	ARM® Cortex®-A7 ARM® Cortex®-M4	DDR3 DDR3L LPDDR2 LPDDR3	1.2 GHz	1.8 V 3.3 V	10 Mbps 100 Mbps 1000 Mbps	2	85 °C	0 °C	USB 2.0 + PHY (1) USB 2.0 OTG + PHY (2)	488-TFBGA	AC'97 CAN eCSPI I2C I2S MMC/SD/SDIO PCIe QSPI SAI UART	Multimedia NEON™ MPE	32 Bit	2
Freescale Semiconductor - NXP MCIMX7D7DVK10SC	A-HAB ARM TZ CAAM CSU SJC SNVS	488-TFBGA (12x12)	Surface Mount	ARM® Cortex®-A7 ARM® Cortex®-M4	DDR3 DDR3L LPDDR2 LPDDR3	1 GHz	1.8 V 3.3 V	10 Mbps 100 Mbps 1000 Mbps	2	95 °C	0 °C	USB 2.0 + PHY (1) USB 2.0 OTG + PHY (2)	488-TFBGA	AC'97 CAN eCSPI I2C I2S MMC/SD/SDIO PCIe QSPI SAI UART	Multimedia NEON™ MPE	32 Bit	2
