1502P Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 4COND 18AWG/22AWG
| Part | Shield Material | Shield Coverage | Cable Type | Conductor Insulation | Wire Gauge | Number of Conductors | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Jacket (Insulation) Thickness [x] | Jacket (Insulation) Thickness [x] | Shield Type | Voltage | Jacket Color | Conductor Strand [custom] | Conductor Strand [custom] | Conductor Material | Length | Length | Jacket (Insulation) Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum | 100 % | Multi-Conductor | Poly-Vinyl Chloride (PVC) | 18 AWG 22 AWG | 4 | 0.205 in | 5.21 mm | -20 ░C | 60 °C | 0.381 mm | 0.015 in | Foil | 300 VDC | Natural | 30 AWG 32 AWG | 7 19 | Copper Tinned | 304.8 m | 1000 ft | Poly-Vinyl Chloride (PVC) |
Belden Inc. | Aluminum | 100 % | Multi-Conductor | Poly-Vinyl Chloride (PVC) | 18 AWG 22 AWG | 4 | 0.205 in | 5.21 mm | -20 ░C | 60 °C | 0.381 mm | 0.015 in | Foil | 300 VDC | Natural | 30 AWG 32 AWG | 7 19 | Copper Tinned | 304.8 m | 1000 ft | Poly-Vinyl Chloride (PVC) |
 Belden Inc. | Aluminum | 100 % | Multi-Conductor | Poly-Vinyl Chloride (PVC) | 18 AWG 22 AWG | 4 | 0.205 in | 5.21 mm | -20 ░C | 60 °C | 0.381 mm | 0.015 in | Foil | 300 VDC | Natural | 30 AWG 32 AWG | 7 19 | Copper Tinned | 152.4 m | 500 ft | Poly-Vinyl Chloride (PVC) |
