2183P Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTI-PAIR 8COND 23AWG BLUE 500'
| Part | Shield Material | Shield Coverage | Jacket Color | Features | Usage | Length [x] | Length [x] | Shield Type | Jacket (Insulation) Material | Cable Type | Voltage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Wire Gauge | Conductor Material | Number of Conductors | Conductor Strand | Length | Length | Conductor Insulation | Ratings |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum | 100 % | Blue | Drain Wire Rip Cord | 4K UHD HDbase-T PoE | 100 ft | 30.5 m | Foil | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair | 300 VDC | 6.6 mm | 0.26 in | 23 AWG | Copper Bare | 8 | Solid | 76.2 m 152.4 m 304.8 m | 250 ft 500 ft 1000 ft | Fluorinated Ethylene-Propylene (FEP) | UL Style CMP |
Belden Inc. | Aluminum | 100 % | Black | Drain Wire Rip Cord | 4K UHD HDbase-T PoE | Foil | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair | 300 VDC | 6.6 mm | 0.26 in | 23 AWG | Copper Bare | 8 | Solid | 76.2 m | 250 ft | Fluorinated Ethylene-Propylene (FEP) | UL Style CMP |
