LDO03C Series
Manufacturer: ARTESYN / Advanced Energy
Beta
⌘K
NON ISOLATED POL DC/DC CONVERTER, 15 W, 590 MV, 5.1 V, 3 A, ADJUSTABLE
| Part | Features | Number of Outputs | Applications | Voltage - Input (Max) [Max] | Mounting Type | Efficiency | Operating Temperature [Max] | Operating Temperature [Min] | Power (Watts) | Voltage - Input (Min) [Min] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Current - Output (Max) [Max] | Voltage - Output 1 [Max] | Voltage - Output 1 [Min] | Type | Package / Case | Control Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ARTESYN / Advanced Energy | SCP | 1 | ITE (Commercial) | 13.8 V | Through Hole | 90 % | 85 °C | -40 C | 15 W | 3 V | 0.37 in | 0.61 in | 9.4 mm | 15.5 mm | 8 mm | 0.31 " | 3 A | 5.1 V | 0.59 V | Non-Isolated PoL Module | Module | Active High Enable |
