896-052 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 52POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Number of Positions/Bay/Row | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Card Type | Contact Type | Color | Gender | Pitch | Pitch | Termination | Mounting Type | Number of Rows [custom] | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 52 | 26 | Copper Alloy | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Non Specified - Dual Edge | Cantilever | Black | Female | 3.18 mm | 0.125 in | Solder | Through Hole | 2 | Dual | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 52 | 26 | Copper Alloy | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Non Specified - Dual Edge | Cantilever | Black | Female | 3.18 mm | 0.125 in | Solder | Right Angle Through Hole | 2 | Dual | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 52 | 26 | Copper Alloy | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Non Specified - Dual Edge | Cantilever | Black | Female | 3.18 mm | 0.125 in | Solder | Right Angle Through Hole | 2 | Dual | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 52 | 26 | Copper Alloy | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Non Specified - Dual Edge | Cantilever | Black | Female | 3.18 mm | 0.125 in | Solder | Through Hole | 2 | Dual | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 52 | 26 | Copper Alloy | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Non Specified - Dual Edge | Cantilever | Black | Female | 3.18 mm | 0.125 in | Wire Wrap | Through Hole | 2 | Dual | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 52 | 26 | Copper Alloy | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Non Specified - Dual Edge | Cantilever | Black | Female | 3.18 mm | 0.125 in | Solder | Right Angle Through Hole | 2 | Dual | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 52 | 26 | Copper Alloy | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Non Specified - Dual Edge | Cantilever | Black | Female | 3.18 mm | 0.125 in | Solder | Through Hole | 2 | Dual | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 52 | 26 | Copper Alloy | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Non Specified - Dual Edge | Cantilever | Black | Female | 3.18 mm | 0.125 in | Solder | Board Edge Straddle Mount | 2 | Dual | 0.156 " | 3.96 mm | Card Extender | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 52 | 26 | Copper Alloy | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Non Specified - Dual Edge | Cantilever | Black | Female | 3.18 mm | 0.125 in | Solder | Through Hole | 2 | Dual | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 52 | 26 | Copper Alloy | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Non Specified - Dual Edge | Cantilever | Black | Female | 3.18 mm | 0.125 in | Solder | Board Edge Straddle Mount | 2 | Dual | 0.128 " | 3.25 mm | Card Extender |
