MPX2010 Series

Catalog

DIFFERENTIAL, PEIZORESISTIVE PRESSURE SENSOR, 0-1.45PSI, 1%, 0-25MV, ROUND, THROUGH HOLE MOUNT

Part	Accuracy	Termination Style	Features	Operating Temperature [Max]	Operating Temperature [Min]	Output Type	Package / Case	Applications	Pressure Type	Voltage - Supply [Max]	Voltage - Supply [Min]	Maximum Pressure [Max]	Maximum Pressure [Max]	Output [Max]	Output [Min]	Port Style	Mounting Type	Operating Pressure	Operating Pressure	Port Size	Port Size
Freescale Semiconductor - NXP MPX2010D	1 %	PC Pin	Temperature Compensated	125 °C	-40 °C	Wheatstone Bridge	4-SIP Module	Board Mount	Differential	16 V	10 VDC	10.88 PSI	75 kPa	25 mV	0 mV	No Port	Through Hole	1.45 PSI	10 kPa
Freescale Semiconductor - NXP MPX2010GSX	1 %	PC Pin	Temperature Compensated	125 °C	-40 °C	Wheatstone Bridge	4-SIP Module	Board Mount	Vented Gauge	16 V	10 VDC	10.88 PSI	75 kPa	25 mV	0 mV	Barbed	Through Hole	1.45 PSI	10 kPa	0.19 "	4.92 mm
