GTB6 Series

Catalog

SENSOR 140MM PNP LO/DO M8

Part	Voltage - Supply [Min]	Voltage - Supply [Max]	Connection Method	Light Source	Response Time	Sensing Distance [Min]	Sensing Distance [Max]	Sensing Distance [Max]	Sensing Distance [Min]	Ingress Protection	Operating Temperature [Max]	Operating Temperature [Min]	Output Configuration	Cable Length	Cable Length	Sensing Method	Sensing Distance	Sensing Distance	Adjustment Type
SICK, Inc. 1052438	10 VDC	30 VDC	Connector M8 4POS	Red LED	625 µs	35 mm	5.512 in	140 mm	1.378 in	IP67	55 °C	-25 °C	PNP - Dark-ON/Light-ON - Selectable
SICK, Inc. 1058769	10 VDC	30 VDC	Cable with Connector	RED (650nm)	500 µs	1 mm	3.937 in	100 mm	0.039 "	IP67			PNP - Dark-ON/Light-ON	0.3 m	11.81 "	Proximity
SICK, Inc. 1052439	10 VDC	30 VDC	Connector M8	RED (650nm)	200 µs					IP67 IP69K	50 °C	-10 °C	NPN - Dark-ON/Light-ON			Proximity	10 mm	0.394 in	Adjustable Potentiometer
SICK, Inc. 1052440	10 VDC	30 VDC	Cable	RED (650nm)	625 µs		9.843 " 250 mm		0.197 in 5 mm	IP67	55 °C	-25 °C	PNP	2 m	78.74 "	Proximity			Adjustable
SICK, Inc. GTB6-N1212	10 VDC	30 VDC	Cable	RED (650nm)	200 µs					IP67 IP69K	50 °C	-10 °C	NPN - Dark-ON/Light-ON	2 m	78.74 "	Proximity	10 mm	0.394 in	Adjustable Potentiometer
SICK, Inc. 1052441	10 VDC	30 VDC	Cable	RED (650nm)	625 µs		9.843 " 250 mm		0.197 in 5 mm	IP67	55 °C	-25 °C	NPN	2 m	78.74 "	Proximity			Adjustable
SICK, Inc. 1052443	10 VDC	30 VDC	Connector M8	RED (650nm)	625 µs		9.843 " 250 mm		0.197 in 5 mm	IP67	55 °C	-25 °C	NPN			Proximity			Adjustable
SICK, Inc. 1052444	10 VDC	30 VDC	Cable	RED (650nm)	625 µs		9.843 " 250 mm		0.197 in 5 mm	IP67	55 °C	-25 °C	PNP	2 m	78.74 "	Proximity			Adjustable
