039533 Series
Manufacturer: Molex
Beta
⌘K
TERM BLOCK PLUG 12POS 5.08MM
| Part | Mounting Type | Voltage - UL | Contact Material | Torque - Screw | Torque - Screw | Wire Strip Length | Features | Termination Style | Pitch [x] | Pitch [x] | Positions Per Level | Type | Number of Positions | Insulation Height | Insulation Height | Contact Mating Finish | Material Flammability Rating | Number of Levels | Operating Temperature [Min] | Operating Temperature [Max] | Wire Gauge or Range - AWG [Min] | Wire Gauge or Range - AWG [Max] | Color | Plug Wire Entry |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | Free Hanging (In-Line) | 300 V | Phosphor Bronze | 0.56 Nm | 5 Lb-In | 5 mm | Positions Stamped Retention Latches (Non-Wire Side) | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 12 | Plug Female Sockets | 12 | 1.02 in | 25.91 mm | Gold | UL94 V-0 | 1 | -40 °C | 105 ░C | 12 AWG | 26 AWG | Green | 270 ° |
 Molex | Free Hanging (In-Line) | 300 V | Phosphor Bronze | 0.56 Nm | 5 Lb-In | 5 mm | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 10 | Plug Female Sockets | 10 | 1.02 in | 25.91 mm | Tin | UL94 V-0 | 1 | -40 °C | 105 ░C | 12 AWG | 26 AWG | Green | 270 ° | |
Molex | Free Hanging (In-Line) | 300 V | Phosphor Bronze | 0.56 Nm | 5 Lb-In | 5 mm | Positions Stamped Retention Latches (Non-Wire Side) | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 18 | Plug Female Sockets | 18 | 1.02 in | 25.91 mm | Tin | UL94 V-0 | 1 | -40 °C | 105 ░C | 12 AWG | 26 AWG | Black | 270 ° |
Molex | Free Hanging (In-Line) | 300 V | Phosphor Bronze | 0.56 Nm | 5 Lb-In | 5 mm | Positions Stamped Retention Latches (Wire Side) | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 8 | Plug Female Sockets | 8 | 1.02 in | 25.91 mm | Gold | UL94 V-0 | 1 | -40 °C | 105 ░C | 12 AWG | 26 AWG | Black | 90 ° |
Molex | Free Hanging (In-Line) | 300 V | Phosphor Bronze | 0.56 Nm | 5 Lb-In | 5 mm | Positions Stamped Retention Latches (Non-Wire Side) | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 7 | Plug Female Sockets | 7 | 1.02 in | 25.91 mm | Gold | UL94 V-0 | 1 | -40 °C | 105 ░C | 12 AWG | 26 AWG | Green | 270 ° |
Molex | Free Hanging (In-Line) | 300 V | Phosphor Bronze | 0.56 Nm | 5 Lb-In | 5 mm | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 22 | Plug Female Sockets | 22 positions | 1.02 in | 25.91 mm | Gold | UL94 V-0 | 1 | -40 °C | 105 ░C | 12 AWG | 26 AWG | Black | 270 ° | |
Molex | Free Hanging (In-Line) | 300 V | Phosphor Bronze | 0.56 Nm | 5 Lb-In | 5 mm | Positions Stamped Retention Latches (Wire Side) | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 8 | Plug Female Sockets | 8 | 1.02 in | 25.91 mm | Tin | UL94 V-0 | 1 | -40 °C | 105 ░C | 12 AWG | 26 AWG | Black | 90 ° |
Molex | Free Hanging (In-Line) | 300 V | Phosphor Bronze | 0.56 Nm | 5 Lb-In | 5 mm | Positions Stamped Retention Latches (Non-Wire Side) | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | Plug Female Sockets | 24 | 1.02 in | 25.91 mm | Gold | UL94 V-0 | 1 | -40 °C | 105 ░C | 12 AWG | 26 AWG | Green | 270 ° | |
Molex | Free Hanging (In-Line) | 300 V | Phosphor Bronze | 0.56 Nm | 5 Lb-In | 5 mm | Positions Stamped Retention Latches (Non-Wire Side) | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 13 | Plug Female Sockets | 13 | 1.02 in | 25.91 mm | Gold | UL94 V-0 | 1 | -40 °C | 105 ░C | 12 AWG | 26 AWG | Green | 270 ° |
Molex | Free Hanging (In-Line) | 300 V | Phosphor Bronze | 0.56 Nm | 5 Lb-In | 5 mm | Positions Stamped Retention Latches (Wire Side) | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 3 | Plug Female Sockets | 1.02 in | 25.91 mm | Tin | UL94 V-0 | 1 | -40 °C | 105 ░C | 12 AWG | 26 AWG | Green | 90 ° |
