ECO-S2 Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

Catalog

CAP ALUM 150UF 20% 400V SNAP TH

...

Part	Tolerance	Voltage - Rated	Size / Dimension [diameter]	Size / Dimension [diameter]	Polarization	Lifetime @ Temp.	Mounting Type	ESR (Equivalent Series Resistance)	Ripple Current @ Low Frequency	Package / Case	Lead Spacing	Lead Spacing	Applications	Capacitance	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Ripple Current @ High Frequency
Panasonic Industrial Automation Sales ECO-S2GB151DA	20 %	400 V	30 mm	1.181 inches	Polar	3000 Hrs	Through Hole	1.105 Ohm	820 mA	Radial Can - Snap-In	0.394 in	10 mm	General Purpose	150 µF	-25 °C	105 ░C	0.984 "	25 mm	934.8 mA
Panasonic Industrial Automation Sales ECO-S2DP561BA	20 %	200 V	22 mm	0.866 in	Polar	3000 Hrs	Through Hole	326 mOhm	2.43 A	Radial Can - Snap-In	0.394 in	10 mm	General Purpose	560 µF	-40 °C	85 °C	1.575 in	40 mm	3.402 A
Panasonic Industrial Automation Sales ECO-S2GP271EA	20 %	400 V	35 mm	1.378 in	Polar	3000 Hrs	Through Hole	675 mOhm	1.67 A	Radial Can - Snap-In	0.394 in	10 mm	General Purpose	270 µF	-25 °C	85 °C	1.181 "	30 mm	2.338 A
Panasonic Industrial Automation Sales ECO-S2HP271EA	20 %	500 V	35 mm	1.378 in	Polar	3000 Hrs	Through Hole	614 mOhm	1.76 A	Radial Can - Snap-In	0.394 in	10 mm	General Purpose	270 µF	-25 °C	85 °C	1.575 in	40 mm	2.464 A
Panasonic Industrial Automation Sales ECO-S2EP271BA	20 %	250 V	22 mm	0.866 in	Polar	3000 Hrs	Through Hole	614 mOhm	1.31 A	Radial Can - Snap-In	0.394 in	10 mm	General Purpose	270 µF	-40 °C	85 °C	1.181 "	30 mm	1.834 A
Panasonic Industrial Automation Sales ECO-S2DP102EA	20 %	200 V	35 mm	1.378 in	Polar	3000 Hrs	Through Hole	199 mOhm	3.25 A	Radial Can - Snap-In	0.394 in	10 mm	General Purpose	1000 µF	-40 °C	85 °C	1.181 "	30 mm	4.55 A
Panasonic Industrial Automation Sales ECO-S2HP680CA	20 %	500 V	25 mm	0.984 "	Polar	3000 Hrs	Through Hole	2.438 Ohm	780 mA	Radial Can - Snap-In	0.394 in	10 mm	General Purpose	68 µF	-25 °C	85 °C	0.984 "	25 mm	1.09 A
Panasonic Industrial Automation Sales ECO-S2AP562EA	20 %	100 V	35 mm	1.378 in	Polar	3000 Hrs	Through Hole	59 mOhm		Radial Can - Snap-In	0.394 in	10 mm	General Purpose	5.6 mF	-40 °C	85 °C	1.772 in	45 mm	6.613 A
Panasonic Industrial Automation Sales ECO-S2GA101BA	20 %	400 V	22 mm	0.866 in	Polar	3000 Hrs	Through Hole	1.326 Ohm	690 mA	Radial Can - Snap-In	0.394 in	10 mm	General Purpose	100 µF	-25 °C	105 ░C	1.457 in	37 mm	966 mA
Panasonic Industrial Automation Sales ECO-S2EP391BA	20 %	250 V	22 mm	0.866 in	Polar	3000 Hrs	Through Hole	468 mOhm	1.91 A	Radial Can - Snap-In	0.394 in	10 mm	General Purpose	390 µF	-40 °C	85 °C	1.575 in	40 mm	2.674 A
